214733 434 Revision A
Fault Codes
Telltale
Short
Description
Full Fault
Description
Recommended
Fix/Check Message
SA SPN
FMI
104 521045
5
Electrical
System
Header Tilt
Low Error
Sensor voltage below 0.5 V. Check sensor power
supply. Adjust and re-calibrate or replace sensor
if necessary.
104 521045 6
Electrical
System
Header Tilt High Error
Sensor voltage above 4.5 V. Check for wiring
damage. Adjust and re-calibrate or replace
sensor if necessary.
104 521045 8
Electrical
System
Header Tilt
Vref Error
Reference voltage error. Check sensor wiring for
damage.
104 521048 3
Electrical
System
Header Height Low Alarm
Sensor voltage below 0.5 V. Check sensor power
supply. Adjust and re-calibrate or replace sensor
if necessary.
104 521048 4
Electrical
System
Header Height High Alarm
Sensor voltage above 4.5 V. Check for wiring
damage. Adjust and re-calibrate or replace
sensor if necessary.
104 521048
5
Electrical
System
Header Height
Low Error
Sensor voltage below 0.5 V. Check sensor power
supply. Adjust and re-calibrate or replace sensor
if necessary.
104 521048 6
Electrical
System
Header Height High Error
Sensor voltage above 4.5 V. Check for wiring
damage. Adjust and re-calibrate or replace
sensor if necessary.
104 521048 8
Electrical
System
Header Height Vref Error
Reference voltage error. Check sensor wiring for
damage.
104 521051 3
Electrical
System
Charge Pressure Low Alarm
Sensor voltage below 0.5 V. Check sensor power
supply and replace sensor as necessary.
104 521051
4
Electrical
System
Charge Pressure High Alarm
Sensor voltage above 4.5 V. Check for wiring
damage and replace sensor as necessary.
104 521051
5
Electrical
System
Charge Pressure
Low Error
Sensor voltage below 0.5 V. Check sensor power
supply and replace sensor as necessary.
104 521051 6
Electrical
System
Charge Pressure High Error
Sensor voltage above 4.5 V. Check for wiring
damage and replace sensor as necessary.
104 521051 8
Electrical
System
Charge Pressure Vref Error
Reference voltage error. Check sensor wiring for
damage.
REFERENCE
