MacDon M1170 - Page 455

214733 439 Revision A
Fault Codes
Telltale
Short
Description
Full Fault
Description
Recommended
Fix/Check Message
SA SPN
FMI
104 521081 3
Electrical System
Cooling Fan Speed Overload
High current on circuit. Check wiring for damage. Contact Dealer.
104 521081 2
Electrical System
Cooling Fan Speed Saturated
Check current output channel on Master Controller.
104 521082 4
Electrical System
Header Raise/Lower
Open Load
Check wiring for damage or breaks. Contact Dealer.
104 521082 5
Electrical System
Header Raise/Lower
Overload
High current on circuit. Check wiring for damage. Contact Dealer.
104 521083
4
Electrical System
Header Tilt Open Load Check circuit for damage. Contact Dealer.
104 521083
5
Electrical System
Header Tilt Overload
Check circuit for damage. Contact Dealer.
104 521085 4
Electrical System
Reel Drive PWM Open Load Check circuit for damage. Contact Dealer.
104 521085
5
Electrical System
Reel Drive PWM Overload Check circuit for damage. Contact Dealer.
104 521086
4
Electrical System
Conveyor Drive PWM
Open Load
Check wiring for damage or breaks. Contact Dealer.
104 521086
5
Electrical System
Conveyor Drive PWM
Overload
High current on circuit. Check wiring for damage. Contact Dealer.
104 521357 3
Electrical System
Interlock Open Open Load
Check wiring for damage or breaks. Contact Dealer.
104 521357
4
Electrical System
Interlock Open Overload
High current on circuit. Check wiring for damage. Contact Dealer.
104 521359 3
Electrical System
Brake Release
Open Load
Check wiring for damage or breaks. Contact Dealer.
104 521359 4
Electrical System
Brake Release Overload
High current on circuit. Check wiring for damage. Contact Dealer.
104 521361 3
Electrical System
Batt. Disc. Open
Open Load
Check wiring for damage or breaks. Contact Dealer.
104 521361
4
Electrical System
Batt. Disc. Open
Overload
High current on circuit. Check wiring for damage. Contact Dealer.
REFERENCE
