MacDon M1170 - Page 456

214733 440 Revision A
Fault Codes
Telltale
Short
Description
Full Fault
Description
Recommended
Fix/Check Message
SA SPN
FMI
104 521364 3
Electrical System
Ignition
Open Load
Check wiring for damage or breaks. Contact Dealer..
104 521364
4
Electrical System
Ignition
Overload
High current on circuit. Check wiring for damage. Contact Dealer.
104 521366 3
Electrical System
Starter Relay
Open Load
Check wiring for damage or breaks. Contact Dealer.
104 521366 4
Electrical System
Starter Relay Overload
High current on circuit. Check wiring for damage. Contact Dealer.
104 521368 3
Electrical System
12 V Sensor Pwr
Firewall 12 V Sensor Power - Open Load
Check wiring for damage or breaks. The following sensors may be affected: hydraulic oil temperature, hydraulic oil level, cooling fan speed, cab forward or engine-forward seat position, or hydraulic oil filter.Contact Dealer.
104 521368
4
Electrical System
12 V Sensor Pwr
Firewall 12 V Sensor Power - Overload
High current on circuit. Check wiring for damage. The following sensors may be affected: hydraulic oil temperature, hydraulic oil level, cooling fan speed, cab forward or engine-forward seat position, or hydraulic oil filter.Contact Dealer.
104 521369 3
Electrical System
Cooling Fan Reverse Open Load
Check wiring for damage or breaks. Contact Dealer.
104 521369 4
Electrical System
Cooling Fan Reverse Overload
High current on circuit. Check wiring for damage. Contact Dealer.
104 521370 3
Electrical System
Reel/Aux Lift Selector
Open Load
Check wiring for damage or breaks. Contact Dealer.
104 521370
4
Electrical System
Reel/Aux Lift Selector
Overload
High current on circuit. Check wiring for damage. Contact Dealer.
104 521371 3
Electrical System
Reel Retract O/P
Open Load
Check wiring for damage or breaks. Contact Dealer.
104 521371 4
Electrical System
Reel Retract O/P
Overload
High current on circuit. Check wiring for damage. Contact Dealer.
104 521372 3
Electrical System
Reel Extend O/P
Open Load
Check wiring for damage or breaks. Contact Dealer.
REFERENCE
