214733 446 Revision A
Fault Codes
Telltale
Short
Description
Full Fault
Description
Recommended
Fix/Check Message
SA SPN
FMI
reel height position, reel fore-aft position, and
hydraulic oil temperature.Contact Dealer.
104 521506
4
Electrical
System
VREF XC10 Firewall Overload
High current on circuit. Check wiring for damage.
The following sensors may be affected: knife
speed, reel speed, left or right draper speed,
header identification, reel height position, reel
fore-aft position, and hydraulic oil temperature.
Contact Dealer.
104 521507 2
Electrical
System
VREF XC10 Chassis
CAN Error
Contact Dealer The following sensors may be
affected: knife pressure, reel pressure, draper
pressure, supercharge pressure, left and right
float position, header height position, header tilt
position, and swath former position.
104 521507 3
Electrical
System
VREF XC10 Chassis Open Load
Check wiring for damage or breaks. The following
sensors may be affected: knife pressure, reel
pressure, draper pressure, supercharge pressure,
left and right float position, header height
position, header tilt position, and swath former
position.Contact Dealer.
104 521507
4
Electrical
System
VREF XC10 Chassis Overload
High current on circuit. Check wiring for damage.
The following sensors may be affected: knife
pressure, reel pressure, draper pressure,
supercharge pressure, left and right float
position, header height position, header tilt
position, and swath former position.Contact
Dealer.
104 521508 1
Windrower
Lift/Fan Hyd Unstable
Instability Detected
If condition persists, contact dealer. Continued
operation may lead to machine damage.
104 521509 19
Electrical
System
Gearbox Oil Level Signal
CAN Error - Gearbox Oil Low
Level Sensor
Contact Dealer.
104 521509 1
Windrower Gearbox Oil Level Low Low Gearbox Oil Level
Low Gearbox Oil Level, or oil level switch failed
or open wiring circuit. Shut off engine and check
oil level. Check sensor wiring and replace sensor
if necessary.
