MacDon M1170 - Page 463

214733 447 Revision A
Fault Codes
Telltale
Short
Description
Full Fault
Description
Recommended
Fix/Check Message
SA SPN
FMI
104 521510 19
Electrical System
Gearbox Oil Level Signal
CAN Error - Gearbox Oil High Level Sensor
Contact Dealer.
104 521510
1
Windrower Gearbox Oil Level High High Gearbox Oil Level
High Gearbox Oil Level, or oil level switch failed. Shut off engine and check oil level. Check sensor wiring and replace sensor if necessary.
176 521104
1
Electrical System
Front Work Lights
EK1 Relay coil open or not present
Check chassis relay module.
176 521104 2
Electrical System
Front Work Lights
EK1 Relay Coil shorted or failed relay driver
Check chassis relay module.
176 521104 3
Electrical System
Front Work Lights
EK1 Relay Normally Open contact is open
Check chassis relay module.
176 521104
4
Electrical System
Front Work Lights
EK1 Relay Normally Closed contact is open
Check chassis relay module.
176 521104
5
Electrical System
Front Work Lights
EK1 Relay coil is not receiving power
Check wiring to chassis relay module EK1. Contact Dealer
176 521104 6
Electrical System
Front Work Lights
EK1 Relay Normally open contact is shorted
Check chassis relay module.
176 521104
7
Electrical System
Front Work Lights
EK1 Relay Normally closed contact is shorted
Check chassis relay module.
176 521111
1
Electrical System
Low Beam Light Cab Fwd
EK2 Relay coil open or not present
Check chassis relay module.
176 521111 2
Electrical System
Low Beam Light Cab Fwd
EK2 Relay Coil shorted or failed relay driver
Check chassis relay module.
176 521111 3
Electrical System
Low Beam Light Cab Fwd
EK2 Relay Normally Open contact is open
Check chassis relay module.
176 521111
4
Electrical
System
Low Beam Light Cab Fwd
EK2 Relay Normally Closed contact is open
Check chassis relay module.
176 521111
5
Electrical System
Low Beam Light Cab Fwd
EK2 Relay coil is not receiving power
Check wiring to chassis relay module EK2. Contact Dealer
176 521111 6
Electrical System
Low Beam Light Cab Fwd
EK2 Relay Normally open contact is shorted
Check chassis relay module.
REFERENCE
