MacDon M1170 - Page 464

214733 448 Revision A
Fault Codes
Telltale
Short
Description
Full Fault
Description
Recommended
Fix/Check Message
SA SPN
FMI
176
521111
7
Electrical System
Low Beam Light Cab Fwd
EK2 Relay Normally closed contact is shorted
Check chassis relay module.
176 521119
1
Electrical System
Tail Lights Engine Fwd
EK3 Relay coil open or not present
Check chassis relay module.
176 521119 2
Electrical System
Tail Lights Engine Fwd
EK3 Relay Coil shorted or failed relay driver
Check chassis relay module.
176 521119 3
Electrical System
Tail Lights Engine Fwd
EK3 Relay Normally Open contact is open
Check chassis relay module.
176 521119
4
Electrical System
Tail Lights Engine Fwd
EK3 Relay Normally Closed contact is open
Check chassis relay module.
176 521119
5
Electrical System
Tail Lights Engine Fwd
EK3 Relay coil is not receiving power
Check wiring to chassis relay module EK3. Contact Dealer.
176 521119 6
Electrical System
Tail Lights Engine Fwd
EK3 Relay Normally open contact is shorted
Check chassis relay module.
176 521119
7
Electrical System
Tail Lights Engine Fwd
EK3 Relay Normally closed contact is shorted
Check chassis relay module.
176 521127 1
Electrical System
Corner Lights, Cab Fwd
EK4 Relay coil open or not present
Check chassis relay module.
176 521127 2
Electrical System
Corner Lights, Cab Fwd
EK4 Relay Coil shorted or failed relay driver
Check chassis relay module.
176 521127 3
Electrical System
Corner Lights, Cab Fwd
EK4 Relay Normally Open contact is open
Check chassis relay module.
176 521127
4
Electrical System
Corner Lights, Cab Fwd
EK4 Relay Normally Closed contact is open
Check chassis relay module.
176 521127
5
Electrical System
Corner Lights, Cab Fwd
EK4 Relay coil is not receiving power
Check wiring to chassis relay module EK4. Contact Dealer.
176 521127 6
Electrical System
Corner Lights, Cab Fwd
EK4 Relay Normally open contact is shorted
Check chassis relay module.
176 521127
7
Electrical System
Corner Lights, Cab Fwd
EK4 Relay Normally closed contact is shorted
Check chassis relay module.
176 521135 1
Electrical System
Rear Roof Work Lights
EK5 Relay coil open or not present
Check chassis relay module.
REFERENCE
