Fault Codes
Telltale
Short
Description
Full Fault
Description
Recommended
Fix/Check Message
SA SPN
FMI
176
521135 2
Electrical System
Rear Roof Work Lights
EK5 Relay Coil shorted or failed relay driver
Check chassis relay module.
176 521135 3
Electrical System
Rear Roof Work Lights
EK5 Relay Normally Open contact is open
Check chassis relay module.
176 521135 4
Electrical System
Rear Roof Work Lights
EK5 Relay Normally Closed contact is open
Check chassis relay module.
176 521135 5
Electrical System
Rear Roof Work Lights
EK5 Relay coil is not receiving power
Check wiring to chassis relay module EK5. Contact Dealer.
176 521135 6
Electrical System
Rear Roof Work Lights
EK5 Relay Normally open contact is shorted
Check chassis relay module.
176 521135
7
Electrical System
Rear Roof Work Lights
EK5 Relay Normally closed contact is shorted
Check chassis relay module.
176 521143 1
Electrical System
High Beam Lights CF
EK6 Relay coil open or not present
Check chassis relay module.
176 521143 2
Electrical System
High Beam Lights CF
EK6 Relay Coil shorted or failed relay driver
Check chassis relay module.
176 521143 3
Electrical System
High Beam Lights CF
EK6 Relay Normally Open contact is open
Check chassis relay module.
176 521143 4
Electrical System
High Beam Lights CF
EK6 Relay Normally Closed contact is open
Check chassis relay module.
176 521143
5
Electrical System
High Beam Lights CF
EK6 Relay coil is not receiving power
Check wiring to chassis relay module EK6. Contact Dealer.
176 521143 6
Electrical System
High Beam Lights CF
EK6 Relay Normally open contact is shorted
Check chassis relay module.
176 521143
7
Electrical System
High Beam Lights CF
EK6 Relay Normally closed contact is shorted
Check chassis relay module.
176 521151
1
Electrical System
Brake Lights, Eng Fwd
EK7 Relay coil open or not present
Check chassis relay module.
176 521151 2
Electrical System
Brake Lights, Eng Fwd
EK7 Relay Coil shorted or failed relay driver
Check chassis relay module.
176 521151 3
Electrical System
Brake Lights, Eng Fwd
EK7 Relay Normally Open contact is open
Check chassis relay module.
