MacDon M1170 - Page 466

214733 450 Revision A
Fault Codes
Telltale
Short
Description
Full Fault
Description
Recommended
Fix/Check Message
SA SPN
FMI
176
521151
4
Electrical System
Brake Lights, Eng Fwd
EK7 Relay Normally Closed contact is open
Check chassis relay module.
176 521151
5
Electrical System
Brake Lights, Eng Fwd
EK7 Relay coil is not receiving power
Check wiring to chassis relay module EK7. Contact Dealer.
176 521151 6
Electrical System
Brake Lights, Eng Fwd
EK7 Relay Normally open contact is shorted
Check chassis relay module.
176
521151
7
Electrical System
Brake Lights, Eng Fwd
EK7 Relay Normally closed contact is shorted
Check chassis relay module.
176 521159
1
Electrical System
Cab Swath Lights, Roof
EK8 Relay coil open or not present
Check chassis relay module.
176 521159 2
Electrical System
Cab Swath Lights, Roof
EK8 Relay Coil shorted or failed relay driver
Check chassis relay module.
176 521159 3
Electrical System
Cab Swath Lights, Roof
EK8 Relay Normally Open contact is open
Check chassis relay module.
176 521159
4
Electrical System
Cab Swath Lights, Roof
EK8 Relay Normally Closed contact is open
Check chassis relay module.
176 521159
5
Electrical System
Cab Swath Lights, Roof
EK8 Relay coil is not receiving power
Check wiring to chassis relay module EK8. Contact Dealer.
176 521159 6
Electrical System
Cab Swath Lights, Roof
EK8 Relay Normally open contact is shorted
Check chassis relay module.
176 521159
7
Electrical System
Cab Swath Lights, Roof
EK8 Relay Normally closed contact is shorted
Check chassis relay module.
176 521167 1
Electrical System
Beacon Lights
EK9 Relay coil open or not present
Check chassis relay module.
176 521167 2
Electrical System
Beacon Lights
EK9 Relay Coil shorted or failed relay driver
Check chassis relay module.
176 521167 3
Electrical System
Beacon Lights
EK9 Relay Normally Open contact is open
Check chassis relay module.
176 521167
4
Electrical System
Beacon Lights
EK9 Relay Normally Closed contact is open
Check chassis relay module.
176 521167
5
Electrical System
Beacon Lights
EK9 Relay coil is not receiving power
Check wiring to chassis relay module EK9. Contact Dealer.
