MacDon M1170 - Page 467

214733 451 Revision A
Fault Codes
Telltale
Short
Description
Full Fault
Description
Recommended
Fix/Check Message
SA SPN
FMI
176
521167
6
Electrical System
Beacon Lights
EK9 Relay Normally open contact is shorted
Check chassis relay module.
176 521167
7
Electrical System
Beacon Lights
EK9 Relay Normally closed contact is shorted
Check chassis relay module.
176 521175 1
Electrical System
Dome Light, Cab
EK10 Relay coil open or not present
Check chassis relay module.
176 521175 2
Electrical System
Dome Light, Cab
EK10 Relay Coil shorted or failed relay driver
Check chassis relay module.
176 521175 3
Electrical System
Dome Light, Cab
EK10 Relay Normally Open contact is open
Check chassis relay module.
176 521175
4
Electrical System
Dome Light, Cab
EK10 Relay Normally Closed contact is open
Check chassis relay module.
176 521175 5
Electrical System
Dome Light, Cab
EK10 Relay coil is not receiving power
Check wiring to chassis relay module EK10. Contact Dealer.
176 521175 6
Electrical System
Dome Light, Cab
EK10 Relay Normally open contact is shorted
Check chassis relay module.
176 521175
7
Electrical System
Dome Light, Cab
EK10 Relay Normally closed contact is shorted
Check chassis relay module.
176 521185 1
Electrical System
Inner work lights EC1 Circuit Breaker Blown Check roof relay module.
176 521185 2
Electrical System
Inner work lights
EC1 Circuit Breaker Not Powered
Check wiring to roof relay module EC1 circuit breaker. Contact dealer.
176 521185 3
Electrical System
Inner work lights EC1 Circuit Breaker Not Used Contact Dealer.
176 521288 1
Electrical System
Outer work lights EC2 Circuit Breaker Blown Check roof relay module.
176
521288 2
Electrical System
Outer work lights
EC2 Circuit Breaker Not Powered
Check wiring to roof relay module EC2 circuit breaker. Contact dealer.
176 521288 3
Electrical System
Outer work lights EC2 Circuit Breaker Not Used Contact Dealer
176 521291 1
Electrical System
Brake Lights, Eng Fwd EC3 Circuit Breaker Blown Check roof relay module.
REFERENCE
