MacDon M1170 - Page 468

214733 452 Revision A
Fault Codes
Telltale
Short
Description
Full Fault
Description
Recommended
Fix/Check Message
SA SPN
FMI
176
521291 2
Electrical System
Brake Lights, Eng Fwd
EC3 Circuit Breaker Not Powered
Check wiring to roof relay module EC3 circuit breaker. Contact dealer.
176 521291 3
Electrical System
Brake Lights, Eng Fwd EC3 Circuit Breaker Not Used Contact Dealer
176 521294 1
Electrical System
Low Beam Light Cab Fwd EC4 Circuit Breaker Blown Check roof relay module
176 521294 2
Electrical System
Low Beam Light Cab Fwd
EC4 Circuit Breaker Not Powered
Check wiring to roof relay module EC4 circuit breaker. Contact dealer.
176 521294 3
Electrical System
Low Beam Light Cab Fwd EC4 Circuit Breaker Not Used Contact Dealer
176 521297 1
Electrical System
Cab Swath Lights, Roof
EC5 Circuit Breaker Blown
Check roof relay module.
176 521297 2
Electrical System
Cab Swath Lights, Roof
EC5 Circuit Breaker Not Powered
Check wiring to roof relay module EC5 circuit breaker. Contact dealer.
176 521297 3
Electrical System
Cab Swath Lights, Roof EC5 Circuit Breaker Not Used Contact Dealer.
176 521300
1
Electrical System
High Beam Lights CF EC6 Circuit Breaker Blown
Check roof relay module.
176 521300 2
Electrical System
High Beam Lights CF
EC6 Circuit Breaker Not Powered
Check wiring to roof relay module EC6 circuit breaker. Contact dealer.
176
521300 3
Electrical System
High Beam Lights CF EC6 Circuit Breaker Not Used Contact Dealer.
176 521303
1
Electrical System
Tail Lights Engine Fwd EC7 Circuit Breaker Blown
Check roof relay module.
176 521303 2
Electrical System
Tail Lights Engine Fwd
EC7 Circuit Breaker Not Powered
Check wiring to roof relay module EC7 circuit breaker. Contact dealer.
176 521303 3
Electrical System
Tail Lights Engine Fwd EC7 Circuit Breaker Not Used Contact Dealer.
176 521306
1
Electrical System
Rear Roof Work Lights EC8 Circuit Breaker Blown Check roof relay module.
176 521306 2
Electrical
System
Rear Roof Work Lights
EC8 Circuit Breaker Not Powered
Check wiring to roof relay module EC8 circuit breaker. Contact dealer.
REFERENCE
