214733 33 Revision A
Header Drive
Knife/Disc
Pump
Piston, 53 cc (3.23 cu. in.)
Max pressure
37,921 kPa (5500 psi)
Flow
151.4 L/min (40 gpm)
Reel
Pump
Gear, 25.2 cc (1.54 cu. in.)
Max pressure
23,994 kPa (3480 psi)
Flow
75.7 L/min (20 gpm)
Draper
Pump
Gear, 19.3 cc (1.18 cu. in.)
Max pressure
23,994 kPa (3480 psi)
Flow
53 L/min (14 gpm)
Lift/Fan Drive
Pump
Piston, 60 cc (3.66 cu. in.)
Max pressure
22,063 kPa (3200 psi)
Flow
0–170.3 L/min (45 gpm)
Header Lift/Tilt
Type
Hydraulic double acting cylinders
Max lift capacity
3810 kg (8400 lb.)
Header Float
Adjustment
Fully in cab adjustable
Automatic
Memory for 3 float settings (deck shift positions on draper)
Options
External booster spring (1 or 2 per side)
Cab
Suspension
4 point spring/shock
Dimensions
Width 1767 mm (69.6 in.)
Depth 1735 mm (68.3 in.)
Height 1690 mm (66.5 in.)
Seat
Operator Cloth, adjustable air ride suspension, seat belt
Training Cloth, folding, cab mounted, seat belt
Windshield wiper
Front 990 mm (39 in.) blade, washer equipped
Rear 560 mm (22 in.) frameless blade, washer equipped
Heater
11.10 kW (37,900 Btu/hr)
Air conditioning
8.73 kW (29,800 Btu/hr)
Electrical outlets
12 V DC 6
USB 2
Mirrors
Two outside (field use), one inside (engine-forward transport)
Radio
AM/FM/CD/USB/Bluetooth radio, antenna, microphone,
and two factory-installed speakers
PRODUCT OVERVIEW
