214733 34 Revision A
Sun Shades
Front and rear
Deluxe Cab Package
Seat
Operator
Leather, adjustable air ride suspension, seat belt,
heated/cooled, lateral isolation, adjustable front cushion
Training
Leather, folding, cab mounted, seat belt
Radio
AM/FM/CD/USB/Bluetooth radio, antenna, microphone,
and two factory-installed speakers
Mirrors
Two power adjustable outside (field use)
Sun shades
Front and rear
System Monitoring
Display
7 in. LCD
Speeds
Ground (mph or km/h), engine (rpm), knife (spm), reel (rpm or
mph/km/h), conveyor (rpm or mph/km/h), cooling fan (rpm)
Pressures
Knife or disc (psi or MPa), reel (psi or MPa), conveyor (psi or MPa),
supercharge (psi or MPa)
Header position
Platform Height, angle, float
Reel Height, fore-aft
Engine parameters
Fuel consumption, load
Tire Options
Drive
Bar 600/65R28
Turf 580/70R26
Caster
Suspended 16.5 L-16.1 with independent suspension
Mud 11x16 with single sided caster (unsuspended)
Frame and Structure
Dimensions
Refer to 2.3 Windrower Dimensions, page 36
Frame to ground (crop clearance)
1160 mm (45.7 in.)
Walking beam max width
3856 mm (151.8 in.) with 3422 mm (134.7 in.) crop clearance
Weight
1
Base
5942 kg (13,100 lb)
2
Max GVW 10,660 kg (23,500 lb.)
Max CGVW
11,794 kg (26,000 lb.)
Header compatibility
Draper
D1XL Series
D1X Series
Rotary
R1 Series
Auger A40DX
NOTE:
Specifications and design are subject to change without notice or obligation to revise previously sold units.
PRODUCT OVERVIEW
1. Weights do not include options.
2. Weight with 600/65R28 bar tires, no fuel/DEF. Hydraulic oil and coolant included in weight.
