MacDon M1170 - Page 491

214733 475 Revision A
J1939
SPN
J1939
FMI
Telltale
Lamp
Cummins
Fault Code
J1939_SPN Description
Detail
107 15
Eng Air
Filter
Amber
5576
Engine Air Filter 1
Differential Pressure
Engine Air Filter Differential
Pressure - Data valid but above
normal operating range - Least
Severe Level
107 16
Eng Air
Filter
Amber
3341
Engine Air Filter 1
Differential Pressure
Engine Air Filter Differential
Pressure - Data valid but above
normal operating range -
Moderately Severe Level
110 0
Eng
coolant
temp
Red
151
Engine Coolant
Temperature
Engine Coolant Temperature -
Data valid but above normal
operational range - Most
Severe Level
110 3
Check
Engine
Amber
144
Engine Coolant
Temperature
Engine Coolant Temperature 1
Sensor Circuit - Voltage above
normal, or shorted to high source
110
4
Check
Engine
Amber
145
Engine Coolant
Temperature
Engine Coolant Temperature 1
Sensor Circuit - Voltage below
normal, or shorted to low source
110 16
Eng
coolant
temp
Amber
146
Engine Coolant
Temperature
Engine Coolant Temperature -
Data valid but above normal
operating range - Moderately
Severe Level
110 31
Check
Engine
None
2659
Engine Coolant
Temperature
Engine Coolant Temperature -
Condition exists
111 1
Coolant
Level
Red
235
Engine Coolant Level
Coolant Level - Data valid but
below normal operational range -
Most Severe Level
111 3
Check
Engine
None
6522
Engine Coolant Level
Coolant Level Sensor 1 Circuit -
Voltage above normal, or shorted
to high source
111 4
Check
Engine
None 6523
Engine Coolant Level
Coolant Level Sensor 1 Circuit -
Voltage below normal, or shorted
to low source
111 17
Coolant
Level
Amber
(Blinking)
2448
Engine Coolant Level
Coolant Level - Data valid but
below normal operating range -
Least Severe Level
111 18
Coolant
Level
Amber
197
Engine Coolant Level
Coolant Level - Data valid but
below normal operating range -
Moderately Severe Level
157 0
Stop
Engine
Red
449
Engine Injector Metering
Rail 1
Injector Metering Rail 1 Pressure -
Data valid but above normal
operational range - Most
Severe Level
157 3
Check
Engine
Amber
451
Engine Injector Metering
Rail 1
Injector Metering Rail 1 Pressure
Sensor Circuit - Voltage above
normal, or shorted to high source
