MacDon M1170 - Page 492

214733 476 Revision A
J1939
SPN
J1939
FMI
Telltale
Lamp
Cummins
Fault Code
J1939_SPN Description
Detail
157 4
Check
Engine
Amber
452
Engine Injector Metering
Rail 1
Injector Metering Rail 1 Pressure
Sensor Circuit - Voltage below
normal, or shorted to low source
157
16
Check
Engine
Amber
553
Engine Injector Metering
Rail 1
Injector Metering Rail 1 Pressure -
Data valid but above normal
operating range - Moderately
Severe Level
157 18
Check
Engine
Amber
559
Engine Injector Metering
Rail 1
Injector Metering Rail 1 Pressure -
Data valid but below normal
operating range - Moderately
Severe Level
168 15
Battery None
6256
Battery Potential / Power
Input 1
Battery 1 Voltage - Data valid but
above normal operating range -
Moderately Severe Level
168 16
Battery
Amber
442
Battery Potential / Power
Input 1
Battery 1 Voltage - Data valid but
above normal operating range -
Moderately Severe Level
168 17 Battery None 6257
Battery Potential / Power
Input 1
Battery 1 Voltage - Data valid but
below normal operating range -
Moderately Severe Level
168 18
Check
Engine
Amber
249
Battery Potential / Power
Input 1
Battery 1 Voltage - Data valid but
below normal operating range -
Moderately Severe Level
175
3
Check
Engine
None
689
Engine Oil Temperature 1
Engine Oil Temperature Sensor 1
Circuit - Voltage above normal, or
shorted to high source
175 4
Check
Engine
None
6525
Engine Oil Temperature 1
Engine Oil Temperature Sensor 1
Circuit - Voltage below normal, or
shorted to low source
190 0
Stop
Engine
Red
234
Engine Speed
Engine Crankshaft Speed/Position
- Data valid but above normal
operational range - Most
Severe Level
190 2
Check
Engine
None
2321
Engine Speed
Engine Crankshaft Speed/Position
- Data is erratic, intermittent, or
incorrect
190 16
Check
Engine
Amber
2468
Engine Speed
Engine Crankshaft Speed/Position
- Data valid but above normal
operating range - Moderately
Severe Level
237 13
Check
Engine
Amber
4517
Vehicle
Identification Number
Vehicle Identification Number -
Out of Calibration
411 2
Check
Engine
Amber
1866
Engine Exhaust Gas
Exhaust Gas Recirculation
Differential Pressure - Data is
erratic, intermittent, or incorrect
