MacDon M1170 - Page 493

214733 477 Revision A
J1939
SPN
J1939
FMI
Telltale
Lamp
Cummins
Fault Code
J1939_SPN Description
Detail
411
3
Check
Engine
Amber
2273
Engine Exhaust Gas
Recirculation 1 Differential
Pressure
Exhaust Gas Recirculation
Differential Pressure Sensor
Circuit - Voltage above normal, or
shorted to high source
411
4
Check
Engine
Amber
2274
Engine Exhaust Gas
Recirculation 1 Differential
Pressure
Exhaust Gas Recirculation
Differential Pressure Sensor
Circuit - Voltage below normal, or
shorted to low source
412 3
Check
Engine
Amber
2375
Engine Exhaust Gas
Exhaust Gas Recirculation
Temperature Sensor Circuit -
Voltage above normal, or shorted
to high source
412
4
Check
Engine
Amber
2376
Engine Exhaust Gas
Exhaust Gas Recirculation
Temperature Sensor Circuit -
Voltage below normal, or shorted
to low source
412 15
Check
Engine
None
2961
Engine Exhaust Gas
Exhaust Gas Recirculation
Temperature - Data valid but
above normal operating range -
Least Severe Level
412 16
Check
Engine
Amber
2962
Engine Exhaust Gas
Exhaust Gas Recirculation
Temperature - Data valid but
above normal operating range -
Moderately Severe Level
441 3
Check
Engine
Amber
293
Auxiliary Temperature 1
Auxiliary Temperature Sensor
Input 1 Circuit - Voltage above
normal, or shorted to high source
441
4
Check
Engine
Amber
294
Auxiliary Temperature 1
Auxiliary Temperature Sensor
Input 1 Circuit - Voltage below
normal, or shorted to low source
441 14
Check
Engine
Amber
6583
Auxiliary Temperature 1
Auxiliary Temperature Sensor
Input 1 - Special Instructions
558 2
Check
Engine
Amber
431
Accelerator Pedal 1 Low
Idle Switch
Accelerator Pedal or Lever Idle
Validation Switch - Data is erratic,
intermittent, or incorrect
558 13
Stop
Engine
Red
432
Accelerator Pedal 1 Low
Idle Switch
Accelerator Pedal or Lever Idle
Validation Switch Circuit - Out of
Calibration
558 19
Stop
Engine
Red
3527
Accelerator Pedal 1 Low
Idle Switch
Accelerator Pedal or Lever Idle
Validation Switch - Received
Network Data In Error
563 9
Check
Engine
Amber
3488
Anti-Lock Braking
(ABS) Active
Anti-Lock Braking (ABS) Controller
- Abnormal update rate
563 31
Check
Engine
None
4215
Anti-Lock Braking
(ABS) Active
Anti-Lock Braking (ABS) Active -
Condition Exists
REFERENCE
