OPERATION
CAUTION
Check to be sure a ll bystanders have cleared the area.
10. Start the engine.
11. Press the header up switch (A) to raise header to
maximum height.
NOTE:
If one end of the header does NOT fully rais e,
rephase the lift cylinders as follows:
a. Press and hold the header up switch until both
cylinders stop moving.
b. Continu e to hold the switch for 3–4 seconds.
Cylinders are now phased.
NOTE:
It may be necessary t o repeat this procedure if
there is a ir in the system.
Figure 4.131: GSL
12. Engage safety props on both lift cylinders as follows:
a. Stop engine and remove key from ignition.
b. Pull lever (A) and rotate towards the header
to release and lower safety prop (B) onto the
lift cylinder.
c. Repeat for opposite lift cylinder.
Figure 4.132: Safety Prop
147649
2
22
Revision A
