MAINTENANCE AND S ERVICING
WARNING
• If electrolyte is spilled or sp lashed on clothin g
or on the body, neutralize it immediately w ith a
solution of baking soda and water, then rinse with
clean water.
• Electrolyte splashe d into the eyes is extremely
dangerous. Should this occur, force the eye open,
and flood with cool, clean water for five minutes.
Call a Doctor immediately.
Figure 5.123: Battery Safety
DANGER
To avoid bodily injury or death from unexpected
startup of the machine, always stop the engine and
remove the key from the ignition before leaving the
operator’s seat for any reason.
1. If the batteries are installed in the windrower, stop the
engine and remove the key.
2. Open the platform on the right side of the cab, refer
to 5.3.1 Opening Platforms (Standard Position), page
309.
3. Add electrolyte in accordance with the battery
manufacturer’s instructions.
4. Close the platform, refer to 5. 3. 2 Closing Platforms
(Standard Position), page 310.
Figure
5.124: Platform Location
Removing Batteries
CAUTION
Do not attempt
to service battery unless you have the proper equipment and experience to perform the
job. Have it do
ne by a qualified Dealer.
DANGER
To avoid bodily injury or death from unexpected startup of the machine, always stop the engine and remove
the key from the ignition before leaving the operator ’s seat for any reason.
1. Stop the engine and remove the key.
2. Open the right cab-forward platform to expose the batteries. Refer to 5.3.1 Opening Platforms (Standard
Position), page 309.
147649 373 Revision A
