Chassis Configuration Settings
GARD 8000 SYS RFL Electronics
April 1, 2012 7-101 973.334.3100
Audio Tone Module Settings Database
This file defines the web pages that configure the audio tone settings. It needs to be loaded only when
the audio board is updated.
Audio Tone Module Status Database
This file defines the web pages that display the audio tone status. It needs to be loaded only when the
audio board is updated.
Audio Tone Module Firmware (.HEX File)
This is the operating software for the audio tone module. This file is only loaded in the case of an
audio tone software upgrade.
61850 Module Settings Database
This file defines the web pages that configure the IEC 61850 Ethernet TPS Module. It needs to be
loaded only when the TPS Module is updated.
61850 Module Status Database
This file defines the web pages that display the IEC 61850 Ethernet TPS Module status. It needs to be
loaded only when the TPS Module is updated.
PLC Module Settings Database
This file defines the web pages that configure the PLC settings. It needs to be loaded only when the
PLC board is updated.
PLC Module Status Database
This file defines the web pages that display the PLC status. It needs to be loaded only when the PLC
board is updated.
PLC Module Test Database
This file defines the spreadsheets required to test the PLC Module.
PLC Processor Software
PLC DSP Software
PLC Forth Software
The above files are the operating software for the PLC module; all three files need to be loaded when a
PLC board is updated.
CAUTION
If your GARD 8000 has more than two PLC Digital Modules installed, remove the additional PLC
Modules from the front of the unit when upgrading to new PLC software. You can only upgrade a
PLC Module with ONE additional PLC Module installed.
Current Differential Relay Settings Database
This file defines the web pages that configure the Current Differential relay settings. It needs to be
loaded only when the current diff board is updated.
Current Differential Relay Status Database
This file defines the web pages that display the current differential relay status. It needs to be loaded
only when the current diff board is updated.
