System Programming Codes (Expert Mode Codes)
P31003-H3550-S403-4-7620, 02/05
A-20 HiPath 3000 V5.0, HiPath 5000 V5.0, Service Manual
pcodes.fm
24 4 Call forwarding, door, external; select door: 0 = deactivate, 1 = activate
24 5 Door opener, DTMF, select station: 0 = denied, 1 = allowed
25 Announcement/Music
25 1 Announcement devices
25 1 1 In system (select announcement device 1 ... 16)
25 1 2 Via server (select announcement device 1 ... 16)
25 2 Type of ann., select ann. device: 1 = Ann. type, 2 = Music on hold, 3 =
Internal music
25 3 Announcement prior to answer; select slot and trunk
25 4 External MOH
(Only enter analog line module stations.)
26 Relays
26 1 Type; select relay 1 to 4 and assign function:
11 = Manual on and off
12 = Off after timeout
13 = Door opener
14 = Speaker amplifier (starting contact for amplifier)
15 = Busy display
16 = Music on hold
17 = Call charge pulse
18 = Second bell
19 = Station active
20 = Announcement
26 2 Switching time
Select relay 1 through 4 and enter up to 3 digits (0 to 255)
26 3 Assigned station
Select relay 1 through 4 and enter stations or groups
(up to 5 digits)
26 4 Relay name; select relay 1 through 4, enter alphanumeric name of max.
16 characters (optiset E memory and optiPoint 600 office only)
27 Sensors (HiPath 3550/HiPath 3350/HiPath 3500/HiPath 3300 only)
27 1 Type: 0 = Alarm, 1 = Call distribution
27 2 Destination station no.; select sensor 1 - 4
External station with seizure code (trunk/direction)
Internal station with station prefix (if programmed)
Table A-3 Expert Mode Codes
