RM0091 Reset and clock control (RCC)

Doc ID 018940 Rev 1 117/742

Refer to Section 2.2.2 on page 37 for the register boundary addresses.

0x28

RCC_AHBRSTR

Res

TSC RST

Res

IOPF RST

Res

IOPD RST

IOPC RST

IOPB RST

IOPA RST

Res.

Reset value 0 0 0000

0x2C

RCC_CFGR2

Res

Res.

PREDIV[3:0]

Reset value 0000

0x30

RCC_CFGR3

Res

Res.

ADCSW

Res.

CECSW

Res.

I2C1SW

Res.

USART1SW[1:0]

Reset value 000 00

0x34

RCC_CR2

Res

HSI14CAL[7:0] HSI14TRIM[14:0]

HSI14DIS

HSI14RDY

HSI14ON

Reset value XXXXXXXX100 0 00 00

Table 19. RCC register map and reset values (continued)
