Direct memory access controller (DMA) RM0091

156/742 Doc ID 018940 Rev 1

Refer to Section 2.2.2 on page 37 for the register boundary addresses.

0x04C

DMA_CPAR4 PA[31:0]

Reset value 00000000000000000000000000000000

0x050

DMA_CMAR4 MA[31:0]

Reset value 00000000000000000000000000000000

0x054 Reserved

0x058

DMA_CCR5

Res.

MEM2MEM

[1:0]

M SIZE [1:0]

PSIZE [1:0]

MINC

PINC

CIRC

DIR

TEIE

HTIE

TCIE

Reset value 00000000000000000000000000000000

0x05C

DMA_CNDTR5

Res.

NDT[15:0]

Reset value 00000000000000000000000000000000

0x060

DMA_CPAR5 PA[31:0]

Reset value 00000000000000000000000000000000

0x064

DMA_CMAR5 MA[31:0]

Reset value 00000000000000000000000000000000

Table 26. DMA register map and reset values (continued)
