RM0091 General-purpose timers (TIM15/16/17)

Doc ID 018940 Rev 1 439/742

Refer to Section 2.2.2 on page 37 for the register boundary addresses.

0x48

TIM16_DCR and

TIM17_DCR

Res.

DBL[4:0]

Res.

DBA[4:0]

Reset value 00000 00000

0x4C

TIM16_DMAR

and

TIM17_DMAR

Res.

DMAB[15:0]

Reset value 0000000000000000

Table 57. TIM16 and TIM17 register map and reset values (continued)

Offset Register

Default Chapter1
