Phaser 6500/WorkCentre 6505 Service Manual Xerox Internal Use Only 4-19
General Troubleshooting
Life Fuser
Sheet
■ 0 Fuser sheet life count.
Life Printer
Sheet
■ 0Printer life count.
Life DTB Waste
■ 0 Belt Waste life count.
Life Y
Waste Toner
■ 0 Yellow waste toner life count.
Life M
Waste Toner
■ 0 Magenta waste toner life count.
Life C
Waste Toner
■ 0 Cyan waste toner life count.
Life K
Waste Toner
■ 0 Black waste toner life count.
Life IU Y Time
■ 0 Yellow drum cycle count.
Life IU M Time
■ 0 Magenta drum cycle count.
Life IU C Time
■ 0 Cyan drum cycle count.
Life IU K Time
■ 0 Black drum cycle count.
Life IU Xero
■ 0 Imaging Unit motor operating time.
Life IU Deve K
■ 0 K Developer sheet count.
Life Manual
Feed
■ 0 Manual Feed slot sheet count.
Life Tray 1
Sheet
■ 0 Tray sheet count.
Life Tray 2
Sheet
■ 0 Tray sheet count.
Life Duplex
Sheet
■ 0 Duplex sheet count.
Life Custom In
■ 0 Custom sheet count.
Life Custom
Out
■ 0 Custom sheet count.
Print
■ Ready Prints current parameter values.
Exit Mode Exits Service Mode.
Complete Exit Complete Exit
■ Exit?
Pressing OK twice, exits the Service
Diagnostic menu.
Test Control Panel Display Test Description

Xerox Phaser 6500 Specifications

General

Monthly Duty Cycle	Up to 40, 000 pages
Duplex Printing	Manual
Print Technology	Laser
Maximum Print Resolution	600 x 600 x 4 dpi
First Page Out Time	As fast as 12 seconds
Connectivity	USB 2.0, Ethernet
Paper Capacity	250 sheets + 1 sheet bypass tray
Supported Operating Systems	Windows, Mac OS, Linux
Print Speed	Up to 24 ppm (color) / Up to 24 ppm (black)
