4-18 Xerox Internal Use Only Phaser 6500/WorkCentre 6505 Service Manual
General Troubleshooting
CMY 20% ■ Ready
■ Processing
20% density pattern of Cyan,
Magenta, and Black combined.
Gradation
■ Ready
■ Processing
Prints a pattern in which the density
of CMYK is varied from 0-100%.
Toner Palle t
Check
Toner Pallet Check Pattern of 100% density all colors.
Contamination
Check
Contamination Check Prints a scale pattern for each color
(sheets 1-4) and the Pitch Chart, a
repeating defects page (sheet 5).
Parameter Reads/writes the parameter values, errors, and life counter
values stored in the printer.
NOTE Print the parameter list using the Print function of the
Parameter menu before changing the value of the
registration.
Slow Scan K to
P
■ -128 *
■ :
■ 127 *
Adjusts registration in the feed
direction.
Slow Scan
600M
■ -128 *
■ :
■ 127 *
Slow Scan
600Y
■ -128 *
■ :
■ 127 *
Slow Scan
600C
■ -128 *
■ :
■ 127 *
Fast Scan KtoM
■ -128 *
■ :
■ 127 *
Adjusts registration in the scan
direction.
Fast Scan KtoY
■ -128 *
■ :
■ 127 *
Fast Scan KtoC
■ -128 *
■ :
■ 127 **
Fast Scan
M-feed
■ -30 *
■ :
■ 30 *
Adjusts registration in the scan
direction.
Fast Scan
Tray 1 & 2
■ -30 *
■ :
■ 30 *
Fast Scan
Duplex
Fast Scan 2
KtoM
■ -1 *
■ :
■ 2 *
Adjusts registration in the scan
direction.
Fast Scan 2
KtoY
■ -1 *
■ :
■ 2 *
Fast Scan 2
KtoC
■ -1 *
■ :
■ 2 *
Life Y Toner
■ 0 Yellow toner cartridge life count.
Life M Toner
■ 0 Magenta toner cartridge life count.
Life C Toner
■ 0 Cyan toner cartridge life count.
Life K Toner
■ 0 Black toner cartridge life count.
Test Control Panel Display Test Description
