Phaser 6500/WorkCentre 6505 Service Manual Xerox Internal Use Only 5-35
Print-Quality Troubleshooting
6 Reseat the Fuser.
Is the image printed correctly?
Complete Go to step 7.
7 Open and close the Front Cover to
reseat the Transfer Belt.
Is the image printed correctly?
Complete Go to step 8.
8 Is the paper damaged when fed
from the Manual Feed slot?
Go to step 9. Go to step 12.
9 Check the setting of the Manual
Feed slot side guides and reset the
side guides if needed.
Is the image printed correctly?
Complete Go to step 10.
10 Inspect the media path.
Is there any contamination?
Clean the
media path,
then go to step
11.
Go to step 12.
11 Is the image printed correctly? Complete Go to step 12.
12 Reseat the Paper Tray.
Is the image printed correctly?
Complete Go to step 13.
13 Reset the Paper Tray side guides.
Is the image printed correctly?
Complete Go to step 14.
14 Replace the media in the Paper Tray.
Is the image printed correctly?
Complete Go to step 15.
15 Inspect the media path.
Is there any contamination?
Clean the
media path,
then go to step
16.
Go to step 17.
16 Is the image printed correctly? Complete Go to step 17.
17 Reseat the Separator Holder.
Is the image printed correctly?
Complete Go to step 18.
18 Replace the Separator Holder
(page 8-6).
Is the image printed correctly?
Complete Go to step 19.
19 Replace the Feed Roller (page 8-9).
Is the image printed correctly?
Complete Go to step 20.
20 NOTE During this check, defeat the
Front Cover interlock switch.
Test the Main Motor (page 4-29):
Engine Diag > Motor Test > Main
Motor, then select the Registration
Clutch test (page 4-33): Engine
Diag > Motor Test > Regi Clutch.
Does the Registration Clutch and
registration rollers operate?
Complete Replace the
Feeder
Assembly
page 8-72.
Troubleshooting Procedure (continued)
Step Actions and Questions Yes No
To Next Page
