8-110 Xerox Internal Use Only Phaser 6500/WorkCentre 6505 Service Manual
Service Parts Disassembly
Replacement Note
When re-installing Gear
T4, make sure the longer
hub protrusion faces the
printer interior.
s6500-292
Gear T4
Hub Protrusion
Printer
Interior
Hub Protrusion
Printer Interior
Gear T4
s6500-GearT4
