10-12 Xerox Internal Use Only Phaser 6500/WorkCentre 6505 Service Manual
Wiring
171 6 G-108 Connects Fuser Assy and Fuser Harness Assy
181 9 D-152 Connects Toner Dispenser Assy (Motor Assy Disp Y) and
Toner Motor Harness Assy
182 9 D-152 Connects Toner Dispenser Assy (Motor Assy Disp M)
and Toner Motor Harness Assy
191 9 D-151 Connects Toner Dispenser Assy (Motor Assy Disp C)
and Toner Motor Harness Assy
192 9 D-150 Connects Toner Dispenser Assy (Motor Assy Disp K) and
Toner Motor Harness Assy
201 8 H-139 Connects Feeder Assy (Humidity Sensor) and Left Side
Harness Assy
202 7 E-123 Connects Control Panel and Harness Assy A-OP-OPP
211 8 I-137 Connects Main Drive Assy (Main Motor) and Main
Motor Harness Assy
221 8 H-137 Connects Sub Drive Assy (Sub Motor) and Sub Motor
Harness Assy
231 7 D-126 Connects Feeder Assy (Feed Solenoid) and Left Side
Harness Assy
232 7 F-126 Connects Feeder Assy (Regi Sensor) and Left Side
Harness Assy
233 7 G-126 Connects Feeder Assy (Manual Feed No Paper Sensor)
and Left Side Harness Assy
234 7 G-125 Connects Feeder Assy (Tray No Paper Sensor) and Left
Side Harness Assy
241 8 G-139 Connects Feed Drive Assy (Color Mode Switching
solenoid) and K-Solenoid Harness
261 8 H-138 Connects Feed Drive Assy (Color Mode Switching
Sensor) and K-Sensor Harness
262 8 I-138 Connects Drive Clutch and K-sensor/Regi Clutch
Harness Assy
271 6 H-111 Connects Dup Relay Harness and Option Harness
272 6 F-110 Connects Dup Relay Harness Assy and Duplex Module
(Duplex Harness Assy)
273 8 H-140 Connects Option Harness and Option Feeder (Tray
Harness Assy)
281 6 C-109 Connects Transfer Assy (ADC Sensor via Harness Assy
CTD SNR2) and Left Side Harness Assy
291 6 G-108 Connects Toner Dispenser Assy (Toner Door Switch)
and Toner Door Switch Harness
311 6 G-110 Connects Toner Dispenser Assy (Connector CRUM Y)
and Toner CRUM Harness Assy
MFP Print Engine Plug/Jack Designators (continued)
P/J Map Coordinates
Remarks
