Xerox Phaser 6500 Service Manual

I – 10 Xerox Internal Use Only Phaser 6500/WorkCentre 6505 Service Manual
Index
Troubleshooting
AC power, 4-67
Control Panel, 4-66
DC Power, 4-68
Error Code, 3-35 to 3-164
Interlock Switch, 4-70
Print Quality, 5-7 to 5-42
U
Unacceptable Paper, A-15
Unfused image, 5-36
Upper Link Pivot Shaft
part number, 9-8
removal, 8-31
USB Port
Type A, 1-5
USB Port, Type B
location, SFP, 1-6
MFP, 1-7
V
Voids, 5-23
W
Warm up time, 1-17
Waste Toner, 2-12, 2-53
Wiring
left side harness, part number, SFP & MFP, 9-17
option harness, MFP, part number, 9-17
option harness, SFP, part number, 9-17
Wiring Diagrams
MFP, 10-37 to 10-51
MFP System Connections, 10-37
SFP, 10-24 to 10-36
SFP System Connections, 10-24
symbols used in diagrams, 10-21
X
Xerographics
component locations, 2-2
process, 2-2

Xerox Phaser 6500 Specifications

General

Monthly Duty Cycle	Up to 40, 000 pages
Duplex Printing	Manual
Print Technology	Laser
Maximum Print Resolution	600 x 600 x 4 dpi
First Page Out Time	As fast as 12 seconds
Connectivity	USB 2.0, Ethernet
Paper Capacity	250 sheets + 1 sheet bypass tray
Supported Operating Systems	Windows, Mac OS, Linux
Print Speed	Up to 24 ppm (color) / Up to 24 ppm (black)
