April 2017
2-83
Xerox® VersaLink® B7025/B7030/B7035 Multifunction Printer
012-210B, 012-211B
Status Indicator RAPs
Launch Issue
012-210B NVM Fail RAP
BSD-ON: BSD 3.6 PWB Communications (ESS PWB/Drive PWB to Finisher)
Procedure
NOTE: Ensure the correct RAP is performed, refer to the 012-210 NVM Fail Entry RAP.
WARNING
Ensure that the electricity to the machine is switched off while performing tasks that do
not need electricity. Refer to GP 10. Disconnect the power cord. Electricity can cause
death or injury. Moving parts can cause injury.
Perform the steps that follow:
1. Check the wiring between the finisher and the IOT.
2. If the fault persists, install a new finisher PWB, PL 13.45 Item 2.
012-211B Stacker Tray Fail RAP
BSD-ON: BSD 13.15 Office Finisher LX Stacker Tray Control
Initial Actions
NOTE: Ensure the correct RAP is performed, refer to the 012-211 Stacker Tray Fail Entry RAP.
WARNING
Ensure that the electricity to the machine is switched off while performing tasks that do
not need electricity. Refer to GP 10. Disconnect the power cord. Electricity can cause
death or injury. Moving parts can cause injury.
• Check for obstructions under the tray.
• Check the operation of the stacker height sensor 1, PL 13.27 Item 16 actuator.
• Check the tray raise/lower mechanism for damage or contamination.
Procedure
Enter dC330 code 012-264. Actuate the stacker height sensor 1, PL 13.27 Item 16. The dis-
play changes.
YN
Check the wiring between J8873 pin 2 and P/J8988 pin 17 for an open or short circuit, or
a loose or damaged connector.
The wiring is good.
YN
Reconnect or repair as necessary.
Measure the voltage between P/J8988 pins 16 and 18 on the finisher PWB. The voltage
is approximately +5VDC.
YN
Install a new finisher PWB, PL 13.45 Item 2.
Measure the voltage between P/J8988 pin 17 on the finisher PWB and ground. Actuate
the stacker height sensor 1.
The voltage changes.
YN
Install a new stacker height sensor 1, PL 13.27 Item 16.
Install a new finisher PWB, PL 13.45 Item 2.
Enter dC330 code 012-263. Manually rotate the encoder, PL 13.15 Item 19 to actuate the
stacker encoder sensor.
The display changes.
YN
Check the wiring between J8875 pin 2 and P/J8988 pin 23 for an open or short circuit, or
a loose or damaged connector.
The wiring is good.
YN
Reconnect or repair as necessary.
Measure the voltage between P/J8988 pins 22 and 24 on the finisher PWB. The voltage
is approximately +5VDC.
YN
Install a new finisher PWB, PL 13.45 Item 2.
A B
