Xerox VersaLink B7025 Service Manual

April 2017
2-450
Xerox® VersaLink® B7025/B7030/B7035 Multifunction Printer
045-310, 045-311, 045-396
Launch Issue
Status Indicator RAPs
045-310 Image Ready RAP
045-310 Controller image preparation failure detected.
Procedure
1. Switch off, then switch on the machine, GP 10.
2. Reload the software, GP 4.
045-311, 045-396 Controller Communication Fail RAP
BSD-ON: BSD 3.1 PWB Communications (ESS PWB to Drive PWB)
045-311 Communication failure between ESS PWB and DRIVE PWB was detected.
045-396 IO setup error of HASIC installed on drive PWB.
Procedure
WARNING
Ensure that the electricity to the machine is switched off while performing tasks that do
not need electricity. Refer to GP 10. Disconnect the power cord. Electricity can cause
death or injury. Moving parts can cause injury.
Perform the steps that follow:
1. Switch off, then switch on the machine, GP 10.
2. Check the connection between the ESS PWB ( P/J1334) and the drive PWB ( P/J401).
3. Install new components as necessary:
• ESS PWB, PL 3.10 Item 6.
• Drive PWB, PL 1.10 Item 3.

Xerox VersaLink B7025 Specifications

General

Print Speed	Up to 25 ppm
Print Resolution	Up to 1200 x 1200 dpi
Copy Resolution	Up to 600 x 600 dpi
Scan Resolution	Up to 600 x 600 dpi
Control Panel	5-inch color touchscreen
Duplex Printing	Standard
Processor	1.05 GHz
Memory	2 GB
Paper Output	250 sheets
Fax Speed	33.6 kbps
Fax Transmission Speed	3 seconds per page
Display	5-inch color touchscreen
Connectivity	Ethernet 10/100/1000 Base-T, High-speed USB 3.0
Functions	Print, Copy, Scan
Media Sizes Supported	A4, A5, A6, B5
Printer Type	Laser
Copy Speed	Up to 25 ppm
Mobile Printing	Apple AirPrint, Google Cloud Print, Xerox Print Service Plug-in for Android
