Xerox VersaLink B7025 Service Manual

April 2017
4-119
Xerox® VersaLink® B7025/B7030/B7035 Multifunction Printer
REP 13.22, REP 13.23
Repairs and Adjustments
Launch Issue
REP 13.22 Eject Motor Assembly
Parts List on PL 13.27
Removal
WARNING
Switch off the electricity to the machine. Refer to GP 10. Disconnect the power cord
from the customer supply while performing tasks that do not need electricity. Electricity
can cause death or injury. Moving parts can cause injury.
1. Undock the finisher, REP 13.5.
2. Remove the booklet maker, REP 13.31.
3. Remove the rear upper cover, REP 13.7.
4. Prepare to remove the eject motor assembly, PL 13.27 Item 3.
a. Disconnect the eject motor connector.
b. Remove the harness from the harness guide.
c. Disconnect both wire harness clamps.
d. Remove both screws from the harness guide, then move the harness guide aside.
e. Disconnect the spring.
5. Remove four screws, then eject motor assembly.
Replacement
The replacement is the reverse of the removal procedure.
REP 13.23 Finisher PWB
Parts List on PL 13.45
Removal
WARNING
Switch off the electricity to the machine. Refer to GP 10. Disconnect the power cord
from the customer supply while performing tasks that do not need electricity. Electricity
can cause death or injury. Moving parts can cause injury.
1. If possible, record the current software level by either:
• Printing the configuration report, GP 14.
• From the user interface Home screen, touch Device, then About. Scroll down to view
the Software Version.
2. Remove the rear upper cover, REP 13.7.
