Xerox VersaLink B7025 Service Manual

April 2017
2-77
Xerox® VersaLink® B7025/B7030/B7035 Multifunction Printer
012-935, 012-935A
Status Indicator RAPs
Launch Issue
012-935 Entrance Sensor Entry RAP
012-935 The finisher entry sensor was detected on.
Procedure
Go to the relevant procedure:
• Integrated office finisher installed, 012-935A Entrance Sensor RAP.
• Office finisher LX installed, 012-935B Entrance Sensor RAP.
012-935A Entrance Sensor RAP
BSD-ON:BSD 12.3 Integrated Office Finisher Transportation
Initial Actions
NOTE: Ensure the correct RAP is performed, refer to the 012-935 Entrance Sensor Entry RAP
WARNING
Ensure that the electricity to the machine is switched off while performing tasks that do
not need electricity. Refer to GP 10. Disconnect the power cord. Electricity can cause
death or injury. Moving parts can cause injury.
• Check the power supply voltage at the customer site for a drop.
• Check the finisher entrance sensor, PL 12.12 Item 19 is correctly installed and free from
foreign objects and that the actuator is not binding.
• Switch off, then switch on the machine, GP 10.
Procedure
Enter dC330 code 012-140. Actuate the finisher entrance sensor. The display changes.
YN
Check the connections of P/J8709 and P/J8729. The connectors are good.
YN
Secure the connections.
Check for an open or short circuit between P/J8709 and P/J8729. The wiring is good.
YN
Repair the open or short circuit.
Measure the voltage between P/J8709 pin 6 (+) on the finisher PWB and ground (-).
The voltage is approximately +5VDC.
YN
Check the +5VDC circuit. Refer to the Wiring Diagrams.
Measure the voltage between P/J8709 pin 5 (+) on the finisher PWB and ground (-).
Actuate the Finisher Entrance Sensor.
The voltage changes.
YN
Install a new finisher entrance sensor, PL 12.12 Item 19.
Check the wires and connectors for an intermittent open or short circuit. If the fault per-
sists, install a new finisher PWB, PL 12.14 Item 1.
Check the wires and connectors for an intermittent open or short circuit. If the fault persists,
install a new finisher PWB, PL 12.14 Item 1.

Xerox VersaLink B7025 Specifications

General

Print Speed	Up to 25 ppm
Print Resolution	Up to 1200 x 1200 dpi
Copy Resolution	Up to 600 x 600 dpi
Scan Resolution	Up to 600 x 600 dpi
Control Panel	5-inch color touchscreen
Duplex Printing	Standard
Processor	1.05 GHz
Memory	2 GB
Paper Output	250 sheets
Fax Speed	33.6 kbps
Fax Transmission Speed	3 seconds per page
Display	5-inch color touchscreen
Connectivity	Ethernet 10/100/1000 Base-T, High-speed USB 3.0
Functions	Print, Copy, Scan
Media Sizes Supported	A4, A5, A6, B5
Printer Type	Laser
Copy Speed	Up to 25 ppm
Mobile Printing	Apple AirPrint, Google Cloud Print, Xerox Print Service Plug-in for Android
