Xerox VersaLink B7025 Service Manual

April 2017
2-102
Xerox® VersaLink® B7025/B7030/B7035 Multifunction Printer
013-307
Launch Issue
Status Indicator RAPs
013-307 Booklet Left Cover Open RAP
BSD-ON: BSD 13.4 Office Finisher LX Booklet Interlock Switching
013-307 Control logic senses that the booklet left cover is open.
Initial Actions
WARNING
Ensure that the electricity to the machine is switched off while performing tasks that do
not need electricity. Refer to GP 10. Disconnect the power cord. Electricity can cause
death or injury. Moving parts can cause injury.
Ensure the left cover, PL 13.50 Item 8 is closed.
Procedure
Measure the voltage between P/J8993 pin 5 on the booklet PWB and ground. +24VDC is
measured.
YN
Check the circuit from P/J8993 to and from J8899 on the booklet stapler cover switch,
PL 13.70 Item 10.
Install a new booklet PWB, PL 13.70 Item 4.

Xerox VersaLink B7025 Specifications

General

Print Speed	Up to 25 ppm
Print Resolution	Up to 1200 x 1200 dpi
Copy Resolution	Up to 600 x 600 dpi
Scan Resolution	Up to 600 x 600 dpi
Control Panel	5-inch color touchscreen
Duplex Printing	Standard
Processor	1.05 GHz
Memory	2 GB
Paper Output	250 sheets
Fax Speed	33.6 kbps
Fax Transmission Speed	3 seconds per page
Display	5-inch color touchscreen
Connectivity	Ethernet 10/100/1000 Base-T, High-speed USB 3.0
Functions	Print, Copy, Scan
Media Sizes Supported	A4, A5, A6, B5
Printer Type	Laser
Copy Speed	Up to 25 ppm
Mobile Printing	Apple AirPrint, Google Cloud Print, Xerox Print Service Plug-in for Android
