Xerox VersaLink B7025 Service Manual

April 2017
2-455
Xerox® VersaLink® B7025/B7030/B7035 Multifunction Printer
057-310, 057-312, 057-311, 313, 314, 315
Status Indicator RAPs
Launch Issue
057-310, 057-312 Drive PWB Communication Fail RAP
057-310 SPI communication data abnormality between the drive PWB and the ESS PWB.
057-312 SPI communication data abnormality between the drive PWB and the ESS PWB
Procedure
Perform the 045-311, 045-396 Controller Communication Fail RAP.
057-311, 313, 314, 315 Drive PWB Fail RAP
057-311 Abnormality in the WDT circuit that monitors the SPI communication status in which
the drive PWB is mounted.
057-313 Drive PWB fuse 13 open circuit was detected.
057-314 Drive PWB fuse 14 open circuit was detected.
057-315 Drive PWB fuse 15 open circuit was detected.
Procedure
WARNING
Ensure that the electricity to the machine is switched off while performing tasks that do
not need electricity. Refer to GP 10. Disconnect the power cord. Electricity can cause
death or injury. Moving parts can cause injury.
1. Switch off, then switch on the machine, GP 10.
2. If the fault persists, install a new drive PWB, PL 1.10 Item 3.

Xerox VersaLink B7025 Specifications

General

Print Speed	Up to 25 ppm
Print Resolution	Up to 1200 x 1200 dpi
Copy Resolution	Up to 600 x 600 dpi
Scan Resolution	Up to 600 x 600 dpi
Control Panel	5-inch color touchscreen
Duplex Printing	Standard
Processor	1.05 GHz
Memory	2 GB
Paper Output	250 sheets
Fax Speed	33.6 kbps
Fax Transmission Speed	3 seconds per page
Display	5-inch color touchscreen
Connectivity	Ethernet 10/100/1000 Base-T, High-speed USB 3.0
Functions	Print, Copy, Scan
Media Sizes Supported	A4, A5, A6, B5
Printer Type	Laser
Copy Speed	Up to 25 ppm
Mobile Printing	Apple AirPrint, Google Cloud Print, Xerox Print Service Plug-in for Android
