Xerox VersaLink B7025 Service Manual

April 2017
2-446
Xerox® VersaLink® B7025/B7030/B7035 Multifunction Printer
041-388, 041-391, 041-603, 041-604
Launch Issue
Status Indicator RAPs
041-388, 041-391 Logic Fail RAP
041-388 When fatal abnormality was detected in marking control.
041-391 Finisher module fatal error was detected.
Procedure
Perform the steps that follow:
1. Switch off, then switch on the machine, GP 10.
2. Reload the software, GP 4.
041-603, 041-604 Environment Sensors Fail RAP
041-603 The value of the temperature sensor exceeds the upper limit.
041-604 The value of the humidity sensor exceeds the upper limit.
Procedure
WARNING
Ensure that the electricity to the machine is switched off while performing tasks that do
not need electricity. Refer to GP 10. Disconnect the power cord. Electricity can cause
death or injury. Moving parts can cause injury.
Perform the steps that follow:
1. Switch off, then switch on the machine, GP 10.
2. Ensure that the fusing unit exhaust fan and the marking unit fan are operating correctly,
refer to:
• 042-330 Fuser Exhaust Fan Fail RAP.
• 043-344 Marking Fan Fail RAP.
3. If the fault persists, install a new ESS PWB, PL 3.10 Item 6.
NOTE: The temperature sensor and humidity sensor are both surface mounted on the
ESS PWB.

Xerox VersaLink B7025 Specifications

General

Print Speed	Up to 25 ppm
Print Resolution	Up to 1200 x 1200 dpi
Copy Resolution	Up to 600 x 600 dpi
Scan Resolution	Up to 600 x 600 dpi
Control Panel	5-inch color touchscreen
Duplex Printing	Standard
Processor	1.05 GHz
Memory	2 GB
Paper Output	250 sheets
Fax Speed	33.6 kbps
Fax Transmission Speed	3 seconds per page
Display	5-inch color touchscreen
Connectivity	Ethernet 10/100/1000 Base-T, High-speed USB 3.0
Functions	Print, Copy, Scan
Media Sizes Supported	A4, A5, A6, B5
Printer Type	Laser
Copy Speed	Up to 25 ppm
Mobile Printing	Apple AirPrint, Google Cloud Print, Xerox Print Service Plug-in for Android
