Xerox VersaLink B7025 Service Manual

April 2017
2-459
Xerox® VersaLink® B7025/B7030/B7035 Multifunction Printer
059-383
Status Indicator RAPs
Launch Issue
059-383 Warm Up Time Fail RAP
BSD-ON: BSD 10.1 Fusing Heat Control (1 of 2)
BSD-ON: BSD 10.2 Fusing Heat Control (2 of 2)
010-383 When transitioning from the wait state, the specified temperature is not reached within
the specified time.
NOTE: This fault may occur when the temperature in the installation environment is low (10
degrees C or lower).
Procedure
WARNING
Ensure that the electricity to the machine is switched off while performing tasks that do
not need electricity. Refer to GP 10. Disconnect the power cord. Electricity can cause
death or injury. Moving parts can cause injury.
Perform the steps that follow:
1. Switch off, then switch on the machine, GP 10.
2. Ensure that the fuser is installed correctly.
3. Check the drawer connector between the fuser and the main unit ( DP612) for damage.
4. Check the connections and wiring between the fuser ( DP612) and the LVPS ( P2) for an
open circuit, short circuit or poor contact.
5. Check the connections and wiring between the fuser (DP612S) and the drive PWB ( P/
J416) for an open circuit, short circuit or poor contact.
6. If the fault persists, install new components as necessary:
• Fuser, PL 10.05 Item 2.
• LVPS, PL 1.10 Item 8.
•Drive PWB, PL 1.10 Item 3.

Xerox VersaLink B7025 Specifications

General

Print Speed	Up to 25 ppm
Print Resolution	Up to 1200 x 1200 dpi
Copy Resolution	Up to 600 x 600 dpi
Scan Resolution	Up to 600 x 600 dpi
Control Panel	5-inch color touchscreen
Duplex Printing	Standard
Processor	1.05 GHz
Memory	2 GB
Paper Output	250 sheets
Fax Speed	33.6 kbps
Fax Transmission Speed	3 seconds per page
Display	5-inch color touchscreen
Connectivity	Ethernet 10/100/1000 Base-T, High-speed USB 3.0
Functions	Print, Copy, Scan
Media Sizes Supported	A4, A5, A6, B5
Printer Type	Laser
Copy Speed	Up to 25 ppm
Mobile Printing	Apple AirPrint, Google Cloud Print, Xerox Print Service Plug-in for Android
