Xerox VersaLink B7025 Service Manual

April 2017
2-501
Xerox® VersaLink® B7025/B7030/B7035 Multifunction Printer
103-310 to 103-313, 103-314
Status Indicator RAPs
Launch Issue
103-310 to 103-313 Hybrid Water Mark RAP
103-310 The secure watermark kit cannot be made available because the hybrid watermark
detection hardware is not installed.
103-311 The secure watermark Kit is not enabled.
103-312 The secure watermark kit cannot be made available because the hybrid watermark
detection hardware for document side 2 is not installed.
103-313 The secure watermark kit did not become available because of insufficient IISS exten-
sion memory.
Procedure
For information only. No service action necessary.
103-314 Prohibited Originals RAP
103-314 Possible prohibited originals (system fail).
Procedure
WARNING
Ensure that the electricity to the machine is switched off while performing tasks that do
not need electricity. Refer to GP 10. Disconnect the power cord. Electricity can cause
death or injury. Moving parts can cause injury.
Perform the steps that follow:
1. Switch off, then switch on the machine, GP 10.
2. Ensure that all connectors on the drive PWB, PL 1.10 Item 3 and the ESS PWB, PL 3.10
Item 6 are securely connected. Ensure all surface mounted modules on both PWBs are
securely connected.
3. Initialise the hard disk, refer to dC355 Image Disk Diagnostics.
4. Reload the software, GP 4.
5. If the fault persists, install new ESS PWB, PL 3.10 Item 6.

Xerox VersaLink B7025 Specifications

General

Print Speed	Up to 25 ppm
Print Resolution	Up to 1200 x 1200 dpi
Copy Resolution	Up to 600 x 600 dpi
Scan Resolution	Up to 600 x 600 dpi
Control Panel	5-inch color touchscreen
Duplex Printing	Standard
Processor	1.05 GHz
Memory	2 GB
Paper Output	250 sheets
Fax Speed	33.6 kbps
Fax Transmission Speed	3 seconds per page
Display	5-inch color touchscreen
Connectivity	Ethernet 10/100/1000 Base-T, High-speed USB 3.0
Functions	Print, Copy, Scan
Media Sizes Supported	A4, A5, A6, B5
Printer Type	Laser
Copy Speed	Up to 25 ppm
Mobile Printing	Apple AirPrint, Google Cloud Print, Xerox Print Service Plug-in for Android
