Xerox VersaLink B7025 Service Manual

April 2017
2-58
Xerox® VersaLink® B7025/B7030/B7035 Multifunction Printer
012-132A, 012-151
Launch Issue
Status Indicator RAPs
YN
Check the +5VDC circuit. Refer to the Wiring Diagrams.
Measure the voltage between the finisher PWB P/J8709 pin 5 (+) and ground (-). Actuate
the finisher entrance sensor.
The voltage changes.
YN
Install a new finisher entrance sensor, PL 12.12 Item 19.
Check the wires and connectors for an intermittent open or short circuit. If the fault per-
sists, install a new finisher PWB, PL 12.14 Item 1.
Check the wires and connectors for an intermittent open or short circuit. If the fault persists,
install a new finisher PWB, PL 12.14 Item 1.
012-151 Compiler Exit Sensor Off Jam Entry RAP
012-151 The compiler exit sensor does not deatuate within a specified time.
Procedure
Go to the relevant procedure:
• Integrated office finisher installed, 012-151A Compiler Exit Sensor Off Jam RAP.
• Office finisher LX installed, 012-151B, 012-152B Compiler Exit Sensor Off Jam RAP.
A

Xerox VersaLink B7025 Specifications

General

Print Speed	Up to 25 ppm
Print Resolution	Up to 1200 x 1200 dpi
Copy Resolution	Up to 600 x 600 dpi
Scan Resolution	Up to 600 x 600 dpi
Control Panel	5-inch color touchscreen
Duplex Printing	Standard
Processor	1.05 GHz
Memory	2 GB
Paper Output	250 sheets
Fax Speed	33.6 kbps
Fax Transmission Speed	3 seconds per page
Display	5-inch color touchscreen
Connectivity	Ethernet 10/100/1000 Base-T, High-speed USB 3.0
Functions	Print, Copy, Scan
Media Sizes Supported	A4, A5, A6, B5
Printer Type	Laser
Copy Speed	Up to 25 ppm
Mobile Printing	Apple AirPrint, Google Cloud Print, Xerox Print Service Plug-in for Android
