012-151A Compiler Exit Sensor Off Jam RAP
BSD-ON: BSD 12.3 Integrated Office Finisher Transportation
Initial Actions
NOTE: Ensure the correct RAP is performed, refer to the 012-151 Compiler Exit Sensor Off
Jam Entry RAP
WARNING
Ensure that the electricity to the machine is switched off while performing tasks that do
not need electricity. Refer to GP 10. Disconnect the power cord. Electricity can cause
death or injury. Moving parts can cause injury.
• Check the compiler exit sensor, PL 12.12 Item 16 is correctly installed and free from for-
eign objects and that the actuator is not binding.
• Switch off, then switch on the machine, GP 10.
Procedure
Check the specifications of paper, GP 15. Paper is in specification.
YN
Load paper that is in specification.
Check the condition of the paper. The paper is in normal condition without any problem
that causes the paper to be bent or caught.
YN
Resolve any problem that causes the paper to be bent or caught.
Check the transport path for a foreign object, deformed part or paper dust. The transport
path is good.
YN
Repair the deformed part(s) or remove the foreign object(s) and paper dust.
Check the exit roll, PL 12.11 Item 10 for wear, deterioration or paper dust. The exit roll is
good.
YN
Remove the paper dust or install a new exit roll, PL 12.11 Item 10.
Check the drive mechanism to the exit roll for a deformed, broken part, and/or belt damage.
The drive mechanism is free of defects.
YN
Repair defects or damage to the drive mechanism. Install new components as necessary,
PL 12.11.
Enter dC330 code 012-150. Actuate the compiler exit sensor. The display changes.
YN
Check the connections of P/J8709 and P/J8728. The connectors are good.
YN
Secure the connections.
Check for an open or short circuit between P/J8709 and P/J8728. The wiring is good.
YN
Repair the open or short circuit.
Measure the voltage between the finisher PWB P/J8709 pin 3 (+) and ground (-). The
voltage is approximately +5VDC.
YN
Check the +5VDC circuit. Refer to the Wiring Diagrams.
Measure the voltage between the finisher PWB P/J8709 pin 2 (+) and ground (-). Actuate
the compiler exit sensor.
The voltage changes.
YN
Install a new compiler exit sensor, PL 12.12 Item 16.
Check the wires and connectors for an intermittent open or short circuit. If the fault per-
sists, install a new finisher PWB, PL 12.14 Item 1.
Enter dC330 code 012-095. The finisher transport motor runs.
YN
Check the connections of P/J8706 and P/J8739. The connectors are good.
YN
Secure the connections.
Check for an open or short circuit between P/J8706 and P/J8739. The wiring is good.
YN
Repair the open or short circuit.
Measure the voltage between the finisher PWB P/J8706 pin 5 (+) and ground (-), and P/
J8706 pin 7 (+) and ground (-).
Each voltage is approximately +24VDC.
YN
Check the +24VDC circuit. Refer to the Wiring Diagrams.
Check the wires and connectors for an intermittent open or short circuit. If the fault per-
sists, install a new components as necessary:
• Finisher transport motor, PL 12.11 Item 17.
• Finisher PWB, PL 12.14 Item 1.
Enter dC330 code 012-013. The sub paddle solenoid energizes and the sub paddle shaft
assembly moves vertically.
YN
Check the sub paddle mechanism for damage The sub paddle mechanism is good.
YN
Repair defects, or install new components as necessary, PL 12.10.
Check the connections of P/J8705 and P/J8734. The connectors are good.
YN
Secure the connections.
Check for an open or short circuit between P/J8705 and P/J8734. The wiring is good.
YN
Repair the open or short circuit.
A
A
B
B
C D
