April 2017
2-470
Xerox® VersaLink® B7025/B7030/B7035 Multifunction Printer
072-105, 072-210
Launch Issue
Status Indicator RAPs
072-105 Registration Sensor Jam (Tray 2) RAP
BSD-ON: BSD 8.5 Registration
072-105 The registration sensor did not actuate within the specified time after the registration
clutch initialized during paper feed from tray 2.
Initial Actions
Check the condition of the paper in tray 2. Refer to GP 15 Paper and Media Size Specifications
Procedure
WARNING
Ensure that the electricity to the machine is switched off while performing tasks that do
not need electricity. Refer to GP 10. Disconnect the power cord. Electricity can cause
death or injury. Moving parts can cause injury.
Refer to the procedures that follow as necessary:
• GP 6 How to Check a Motor.
• GP 7 How to Check a Sensor.
• GP 8 How to Check a Solenoid or Clutch.
Perform the steps that follow:
1. Check for obstructions in the paper path.
2. Check the tray 2 feed roll, nudger roll and retard roll, PL 80.25 for foreign substances or
wear. Clean or install new components as necessary.
3. Enter dC330, code 077-104. Check the registration sensor, PL 80.55 Item 4.
4. Enter dC330, code 077-002. Check the registration clutch, PL 80.55 Item 11.
5. Enter dC330, code 077-001. Check the take away clutch, PL 40.10 Item 5.
6. Enter dC330, code 077-033. As necessary, perform the steps that follow:
• Check the 1TM takeaway motor, PL 70.17 Item 4.
• Check the 3TM takeaway motor, PL 70.23 Item 4.
• Check the STM takeaway motor, PL 70.28 Item 2.
• Check the TTM takeaway motor, PL 70.85 Item 2.
7. Check the drive gears, PL 80.10 for wear or damage. Install new components as neces-
sary.
8. Check the drive assembly, PL 40.10 Item 7 for wear or damage.
9. If the fault persists, install new components as necessary:
• 1TM PWB, PL 70.17 Item 5.
• 3TM PWB, PL 70.23 Item 5.
•STM PWB, PL 70.28 Item 4.
• TTM PWB, PL 70.90 Item 1.
•Drive PWB, PL 1.10 Item 3.
• ESS PWB,PL 3.10 Item 6.
072-210 Tray 2 Lift Fail RAP
BSD-ON: BSD 7.8 Tray 2 Paper Stacking (STM)
BSD-ON: BSD 7.9 Tray 2 Paper Stacking (1TM)
BSD-ON: BSD 7.10 Tray 2 Paper Stacking (3TM)
BSD-ON: BSD 7.19 Tray 2 Paper Stacking (TTM)
071-210 Tray 2 lift NG has occurred three consecutive times.
Initial Actions
• Check for obstructions behind the tray.
• Ensure that the tray is loaded correctly.
• Ensure the tray is pushed fully home.
• Check the drive system between the bottom plate and the tray 2 feed/lift motor for opera-
tion failure.
Procedure
WARNING
Ensure that the electricity to the machine is switched off while performing tasks that do
not need electricity. Refer to GP 10. Disconnect the power cord. Electricity can cause
death or injury. Moving parts can cause injury.
Refer to the procedures that follow as necessary:
• GP 6 How to Check a Motor.
• GP 7 How to Check a Sensor.
Perform the steps that follow:
1. Enter dC330, code 072-102. Check the tray 2 level sensor, PL 80.20 Item 6.
2. Enter dC330, code 072-002. Check the tray 2 feed/lift motor, PL 80.20 Item 4.
3. Check the drive gears, PL 80.20 for wear or damage. Install new components as neces-
sary.
4. If the fault persists, install new components as necessary:
•1TM PWB, PL 70.17 Item 5.
•3TM PWB, PL 70.23 Item 5.
• STM PWB, PL 70.28 Item 4.
• TTM PWB, PL 70.90 Item 1.
To Next Page
