Xerox VersaLink B7025 Service Manual

April 2017
2-312
Xerox® VersaLink® B7025/B7030/B7035 Multifunction Printer
024-701, 024-702
Launch Issue
Status Indicator RAPs
024-701 Invalid Instruction of Face Inversion RAP
024-701 Job cancellation due to invalid invert instruction.
Procedure
Advise the customer to use paper that is in specification. Refer to GP 15 Paper and Media Size
Specifications.
024-702 Paper Jam RAP
024-702 Job cancellation due to paper jam.
Procedure
WARNING
Ensure that the electricity to the machine is switched off while performing tasks that do
not need electricity. Refer to GP 10. Disconnect the power cord. Electricity can cause
death or injury. Moving parts can cause injury.
Check the sensors that follow:
• Tray 2 feed out sensor. Refer to the 073-106 Tray 2 Feed Out Sensor RAP.
• Tray 4 feed out sensor. Refer to the 074-101, 103, 900 Tray 4 Misfeed RAP.
• Registration sensor. Refer to the 071-105 Registration Sensor Jam (Tray 1) RAP.
• Fuser Unit exit sensor. Refer to the 077-104, 109, 113, 901 Fuser Exit Sensor Jam RAP.
• Exit 2 sensor. Refer to the 077-105 Exit Sensor 2 Jam RAP.

Xerox VersaLink B7025 Specifications

General

Print Speed	Up to 25 ppm
Print Resolution	Up to 1200 x 1200 dpi
Copy Resolution	Up to 600 x 600 dpi
Scan Resolution	Up to 600 x 600 dpi
Control Panel	5-inch color touchscreen
Duplex Printing	Standard
Processor	1.05 GHz
Memory	2 GB
Paper Output	250 sheets
Fax Speed	33.6 kbps
Fax Transmission Speed	3 seconds per page
Display	5-inch color touchscreen
Connectivity	Ethernet 10/100/1000 Base-T, High-speed USB 3.0
Functions	Print, Copy, Scan
Media Sizes Supported	A4, A5, A6, B5
Printer Type	Laser
Copy Speed	Up to 25 ppm
Mobile Printing	Apple AirPrint, Google Cloud Print, Xerox Print Service Plug-in for Android
