Status Indicator RAPs
Launch Issue
YN
Install a new rear tamper home sensor, PL 12.25 Item 9.
Check the wires and connectors for an intermittent open or short circuit. If the fault per-
sists, install a new finisher PWB, PL 12.14 Item 1.
Enter dC330 code 012-026 and 012-029 alternately. The rear tamper motor runs.
YN
Check the connections of P/J8710 and J8737. The connectors are good.
YN
Secure the connections.
Check for an open wire or short circuit between P/J8710 and J8737. The wiring is
good.
YN
Repair the open or short circuit.
Measure the voltage between the finisher PWB P/J8710 pin 1 (+) and ground (-), and
between P/J8710 pin 3 (+) and ground (-).
The voltage is approximately +24VDC.
YN
Check the +24VDC circuit. Refer to the Wiring Diagrams. If the fault persists, install
a new finisher PWB, PL 12.14 Item 1.
Install a new rear tamper motor, PL 12.26 Item 15. If the fault persists, install a new fin-
isher PWB, PL 12.14 Item 1.
Check the wires and connectors for an intermittent open or short circuit. If the fault persists,
install a new finisher PWB, PL 12.14 Item 1.
012-259, 012-280 Eject Home Sensor Fail RAP
BSD-ON: BSD 12.6 Integrated Office Finisher Set Eject (1 of 2)
012-259 The eject home sensor failed to actuate within the specified time.
012-280 The eject home sensor failed to deactuate within the specified time.
Initial Actions
WARNING
Ensure that the electricity to the machine is switched off while performing tasks that do
not need electricity. Refer to GP 10. Disconnect the power cord. Electricity can cause
death or injury. Moving parts can cause injury.
• Check the eject home sensor, PL 12.26 Item 9 is correctly installed, not broken and has
no foreign object.
• Switch off, then switch on the machine, GP 10.
Procedure
Check the eject mechanism, PL 12.25 for a deformed or broken part and not-seated belts.
The mechanism is good.
YN
Repair the mechanism. Install new components as necessary, PL 12.25.
Enter dC330 code 012-252. Actuate the eject home sensor. The display changes.
YN
Check the connections of P/J8700 and P/J8725. The connectors are good.
YN
Secure the connections.
Check for an open wire or short circuit between P/J8700 and P/J8725. The wiring is
good.
YN
Repair the open wire or short circuit.
Measure the voltage between the finisher PWB P/J8700 pin 9 (+) and ground (-). The
voltage is approximately +5VDC.
YN
Check the +5VDC circuit. Refer to the Wiring Diagrams.
Measure the voltage between the finisher PWB P/J8700 pin 2 (+) and ground (-). Actuate
the eject home sensor.
The voltage changes
YN
Install a new eject home sensor, PL 12.26 Item 9.
Check the wires and connectors for an intermittent open or short circuit. If the fault per-
sists, install a new finisher PWB, PL 12.14 Item 1.
Enter dC330 code 012-054 and 012-056 alternately. The eject motor runs.
