Xerox VersaLink B7025 Service Manual

April 2017
2-311
Xerox® VersaLink® B7025/B7030/B7035 Multifunction Printer
024-616 to 024-621, 024-700
Status Indicator RAPs
Launch Issue
024-616 to 024-621 Serial/Product Number Restore RAP
024-616 Serial number master was restored automatically.
024-617 Serial number backup 1 was restored automatically.
024-618 Serial number backup 2 was restored automatically.
024-619 Product number master was restored automatically.
024-620 Product number backup 1 was restored automatically.
024-621 Product number backup 2 was restored automatically.
Procedure
For information only, no service action necessary.
024-700 Memory Shortage or No Hard Disk RAP
BSD-ON: BSD 3.9 ESS
024-700 A job that could not be printed due to insufficient system memory or hard disk not
installed was received.
Procedure
WARNING
Ensure that the electricity to the machine is switched off while performing tasks that do
not need electricity. Refer to GP 10. Disconnect the power cord. Electricity can cause
death or injury. Moving parts can cause injury.
Perform the steps that follow:
1. Remove, then re-install the SD memory card, PL 3.10 Item 11. If necessary, install a new
memory card.
2. Ensure that the connectors from the hard disk drive, PL 3.10 Item 2 to the ESS PWB, PL
3.10 Item 6 are securely connected.
3. If the fault persists, install a new hard disk drive, PL 3.10 Item 2.

Xerox VersaLink B7025 Specifications

General

Print Speed	Up to 25 ppm
Print Resolution	Up to 1200 x 1200 dpi
Copy Resolution	Up to 600 x 600 dpi
Scan Resolution	Up to 600 x 600 dpi
Control Panel	5-inch color touchscreen
Duplex Printing	Standard
Processor	1.05 GHz
Memory	2 GB
Paper Output	250 sheets
Fax Speed	33.6 kbps
Fax Transmission Speed	3 seconds per page
Display	5-inch color touchscreen
Connectivity	Ethernet 10/100/1000 Base-T, High-speed USB 3.0
Functions	Print, Copy, Scan
Media Sizes Supported	A4, A5, A6, B5
Printer Type	Laser
Copy Speed	Up to 25 ppm
Mobile Printing	Apple AirPrint, Google Cloud Print, Xerox Print Service Plug-in for Android
