Xerox VersaLink B7025 Service Manual

April 2017
2-331
Xerox® VersaLink® B7025/B7030/B7035 Multifunction Printer
024-976, 977, 979, 024-982
Status Indicator RAPs
Launch Issue
024-976, 977, 979 Finisher Staple Error RAP
024-976 After the staple motor started forward rotation, the staple home sensor did not turn on
within 450ms, and after the staple motor started reverse rotation, the stapler head home sen
-
sor turned on within 200ms.
024-977 Stapler feed ready fail.
024-977 Staple near empty or staple feed failure was detected.
Procedure
WARNING
Ensure that the electricity to the machine is switched off while performing tasks that do
not need electricity. Refer to GP 10. Disconnect the power cord. Electricity can cause
death or injury. Moving parts can cause injury.
Perform the steps that follow:
1. Install a new staple cartridge as necessary, (integrated office finisher), PL 12.11 Item 3 or
(office finisher LX), PL 13.20 Item 15.
2. If the fault persists, perform the 012-291 Stapler Fail Entry RAP.
024-982 Stacker Tray Lower Safety RAP
024-982 Finisher stacker tray lower safety.
Procedure
Perform the 012-213 Stacker Tray Lower Limit Failure RAP.

Xerox VersaLink B7025 Specifications

General

Print Speed	Up to 25 ppm
Print Resolution	Up to 1200 x 1200 dpi
Copy Resolution	Up to 600 x 600 dpi
Scan Resolution	Up to 600 x 600 dpi
Control Panel	5-inch color touchscreen
Duplex Printing	Standard
Processor	1.05 GHz
Memory	2 GB
Paper Output	250 sheets
Fax Speed	33.6 kbps
Fax Transmission Speed	3 seconds per page
Display	5-inch color touchscreen
Connectivity	Ethernet 10/100/1000 Base-T, High-speed USB 3.0
Functions	Print, Copy, Scan
Media Sizes Supported	A4, A5, A6, B5
Printer Type	Laser
Copy Speed	Up to 25 ppm
Mobile Printing	Apple AirPrint, Google Cloud Print, Xerox Print Service Plug-in for Android
