Xerox VersaLink B7025 Service Manual

April 2017
2-277
Xerox® VersaLink® B7025/B7030/B7035 Multifunction Printer
018-764, 018-770
Status Indicator RAPs
Launch Issue
018-764 LDAP Protocol Errors 64 to 69 and 71 RAP
018-764 LDAP protocol error 64 at address book operation (naming violation).
018-765 LDAP protocol error 65 at address book operation (object class specification error).
018-766 LDAP protocol error 66 at address book operation (entries other than termination can-
not be executed).
018-767 LDAP protocol error 67 at Address Book operation (cannot be executed at RDN).
018-768 LDAP protocol error 68 at address book operation (the specified entry already exists).
018-769 LDAP protocol error 69 at address book operation (object class cannot be changed).
018-771 LDAP protocol error 71 at address book operation (influence on multiple DSA).
Procedure
Verify that print jobs are printing or print a configuration report and verify that network setup
settings are indicated.
The printer is operational or the configuration report indicates
valid network settings.
YN
Check for damage with the network connection. If there is no damage then there is a
problem with the network. Inform the customer that the network requires service.
There is a problem with the LDAP setups on the machine or with the remote LDAP server.
Advise the customer to verify the machine LDAP setups. If the check is good, there may be a
problem with the remote LDAP server.
018-770 LDAP Protocol Error 70 RAP
018-770 LDAP protocol error 70 at Address Book operation (search target is too large).
Procedure
Verify that print jobs are printing or print a configuration report and verify that network setup
settings are indicated.
The printer is operational or the configuration report indicates
valid network settings.
YN
Check for damage with the network connection. If there is no damage then there is a
problem with the network. Tell the customer that the network requires service.
Ask the customer to retry search with narrower search target by changing search condition/
search start position in Address Book internal data. If the check is OK, there may be a problem
with the remote LDAP server.

Xerox VersaLink B7025 Specifications

General

Print Speed	Up to 25 ppm
Print Resolution	Up to 1200 x 1200 dpi
Copy Resolution	Up to 600 x 600 dpi
Scan Resolution	Up to 600 x 600 dpi
Control Panel	5-inch color touchscreen
Duplex Printing	Standard
Processor	1.05 GHz
Memory	2 GB
Paper Output	250 sheets
Fax Speed	33.6 kbps
Fax Transmission Speed	3 seconds per page
Display	5-inch color touchscreen
Connectivity	Ethernet 10/100/1000 Base-T, High-speed USB 3.0
Functions	Print, Copy, Scan
Media Sizes Supported	A4, A5, A6, B5
Printer Type	Laser
Copy Speed	Up to 25 ppm
Mobile Printing	Apple AirPrint, Google Cloud Print, Xerox Print Service Plug-in for Android
