Xerox VersaLink B7025 Service Manual

April 2017
2-14
Xerox® VersaLink® B7025/B7030/B7035 Multifunction Printer
01C
Launch Issue
Status Indicator RAPs
01C +24VDC Power Fault RAP
BSD-ON: BSD 1.2 Main Power On (2 of 2)
BSD-ON: BSD 1.5 DC Power Generation (2 of 2)
Procedure
WARNING
Ensure that the electricity to the machine is switched off while performing tasks that do
not need electricity. Refer to GP 10. Disconnect the power cord. Electricity can cause
death or injury. Moving parts can cause injury.
WARNING
Take care when measuring AC mains (line) voltage. Electricity can cause death or injury.
Check the voltage between the LVPS ( P/J501 pin 1) and ground. +24VDC is measured.
YN
Check the voltage between P1 pin 1 and pin 3 on the LVPS. The AC power supply is
within specification, GP 17.
YN
Perform the 01A AC Power RAP.
Switch off the machine, GP 10. Disconnect P/J501 from the LVPS. Wait 15 seconds,
then switch on the machine, GP 10. Check the voltage between the LVPS ( P/J501 pin 1)
and ground.
+24VDC is measured.
YN
Install a new LVPS, PL 1.10 Item 8.
Check the +24VDC circuit for a short circuit to frame. Refer to the Wiring Diagrams.
Check the wiring of the suspect component for an open circuit or poor contact. Refer to the
Wiring Diagrams.

Xerox VersaLink B7025 Specifications

General

Print Speed	Up to 25 ppm
Print Resolution	Up to 1200 x 1200 dpi
Copy Resolution	Up to 600 x 600 dpi
Scan Resolution	Up to 600 x 600 dpi
Control Panel	5-inch color touchscreen
Duplex Printing	Standard
Processor	1.05 GHz
Memory	2 GB
Paper Output	250 sheets
Fax Speed	33.6 kbps
Fax Transmission Speed	3 seconds per page
Display	5-inch color touchscreen
Connectivity	Ethernet 10/100/1000 Base-T, High-speed USB 3.0
Functions	Print, Copy, Scan
Media Sizes Supported	A4, A5, A6, B5
Printer Type	Laser
Copy Speed	Up to 25 ppm
Mobile Printing	Apple AirPrint, Google Cloud Print, Xerox Print Service Plug-in for Android
