Xerox VersaLink B7025 Service Manual

April 2017
2-107
Xerox® VersaLink® B7025/B7030/B7035 Multifunction Printer
016-214, 016-215, 016-216
Status Indicator RAPs
Launch Issue
016-214 SW Option Fail (Fax Card) RAP
016-214 The fax card was not installed or an error was detected when SW optional function
was enabled.
Procedure
WARNING
Ensure that the electricity to the machine is switched off while performing tasks that do
not need electricity. Refer to GP 10. Disconnect the power cord. Electricity can cause
death or injury. Moving parts can cause injury.
Perform the steps that follow:
1. Switch off, then switch on the machine, GP 10.
2. Ensure all fax PWBs are correctly installed, PL 20.05.
016-215, 016-216 SW Option Fail RAP
016-215 The scanner functions cannot be executed due to a JPEG board error or JPEG board
not installed.
016-216 The system detected that the extension memory was not installed.
Procedure
WARNING
Ensure that the electricity to the machine is switched off while performing tasks that do
not need electricity. Refer to GP 10. Disconnect the power cord. Electricity can cause
death or injury. Moving parts can cause injury.
Perform the steps that follow:
1. Switch off, then switch on the machine, GP 10.
2. Install a new ESS PWB, PL 3.10 Item 6.

Xerox VersaLink B7025 Specifications

General

Print Speed	Up to 25 ppm
Print Resolution	Up to 1200 x 1200 dpi
Copy Resolution	Up to 600 x 600 dpi
Scan Resolution	Up to 600 x 600 dpi
Control Panel	5-inch color touchscreen
Duplex Printing	Standard
Processor	1.05 GHz
Memory	2 GB
Paper Output	250 sheets
Fax Speed	33.6 kbps
Fax Transmission Speed	3 seconds per page
Display	5-inch color touchscreen
Connectivity	Ethernet 10/100/1000 Base-T, High-speed USB 3.0
Functions	Print, Copy, Scan
Media Sizes Supported	A4, A5, A6, B5
Printer Type	Laser
Copy Speed	Up to 25 ppm
Mobile Printing	Apple AirPrint, Google Cloud Print, Xerox Print Service Plug-in for Android
