April 2017
2-326
Xerox® VersaLink® B7025/B7030/B7035 Multifunction Printer
024-954, , 024-955
Launch Issue
Status Indicator RAPs
024-954, 024-958 Bypass Tray Fault RAP
BSD-ON: BSD 7.13 Bypass Tray Paper Sensing
024-954 The bypass tray is empty.
024-958 Bypass tray paper size mismatch.
Initial Actions
WARNING
Ensure that the electricity to the machine is switched off while performing tasks that do
not need electricity. Refer to GP 10. Disconnect the power cord. Electricity can cause
death or injury. Moving parts can cause injury.
Switch off, then switch on the machine, GP 10.
Procedure
Enter dC330, code 075-100, bypass tray no paper sensor. Manually actuate the bypass tray no
paper sensor, PL 70.40 Item 12.
The display changes.
YN
Check the bypass tray no paper sensor, refer to GP 7 How to Check a Sensor.
Install new components as necessary:
• Bypass tray no paper sensor, PL 70.40 Item 12.
•Drive PWB, PL 1.10 Item 3.
024-955 Tray 6 Empty RAP
BSD-ON: BSD 7.15 HCF Paper Stacking
024-955 Tray 6 is empty.
Initial Actions
WARNING
Ensure that the electricity to the machine is switched off while performing tasks that do
not need electricity. Refer to GP 10. Disconnect the power cord. Electricity can cause
death or injury. Moving parts can cause injury.
Switch off, then switch on the machine, GP 10.
Procedure
Enter dC330, code 078-200, HCF no paper sensor. Manually actuate the HCF no paper sen-
sor, PL 80.61 Item 19. The display changes.
YN
Check the HCF no paper sensor. Refer to GP 7 How to Check a Sensor.
Perform the 078-250 HCF Lift Fault RAP. Check the HCF feed/lift motor. If the fault persists,
install new components as necessary:
• HCF no paper sensor, PL 80.61 Item 19.
• HCF PWB, PL 70.60 Item 9.
To Next Page
