Xerox VersaLink B7025 Service Manual

April 2017
2-444
Xerox® VersaLink® B7025/B7030/B7035 Multifunction Printer
041-334, 041-335
Launch Issue
Status Indicator RAPs
041-334 Drive PWB F11 Blown RAP
BSD-ON: BSD 1.5 DC Power Generation (2 of 2)
BSD-ON: BSD 1.7 Option DC Power Distribution
041-334 Drive PWB fuse 11 open circuit was detected.
Procedure
WARNING
Ensure that the electricity to the machine is switched off while performing tasks that do
not need electricity. Refer to GP 10. Disconnect the power cord. Electricity can cause
death or injury. Moving parts can cause injury.
Perform the steps that follow:
1. Check the finisher for overcurrent and overvoltage. Repair the wiring or install new com-
ponents as necessary.
2. After the faulty circuit has been repaired, install a new drive PWB, PL 1.10 Item 3.
041-335 Drive PWB F12 Blown RAP
BSD-ON: BSD 1.5 DC Power Generation (2 of 2)
BSD-ON: BSD 10.5 Fused Paper Exit 2
041-335 Drive PWB fuse 12 open circuit was detected.
Procedure
WARNING
Ensure that the electricity to the machine is switched off while performing tasks that do
not need electricity. Refer to GP 10. Disconnect the power cord. Electricity can cause
death or injury. Moving parts can cause injury.
Perform the steps that follow:
1. Check the fuser exhaust fan for overcurrent and overvoltage. Repair the wiring or install
new components as necessary.
2. After the faulty circuit has been repaired, install a new drive PWB, PL 1.10 Item 3.

Xerox VersaLink B7025 Specifications

General

Print Speed	Up to 25 ppm
Print Resolution	Up to 1200 x 1200 dpi
Copy Resolution	Up to 600 x 600 dpi
Scan Resolution	Up to 600 x 600 dpi
Control Panel	5-inch color touchscreen
Duplex Printing	Standard
Processor	1.05 GHz
Memory	2 GB
Paper Output	250 sheets
Fax Speed	33.6 kbps
Fax Transmission Speed	3 seconds per page
Display	5-inch color touchscreen
Connectivity	Ethernet 10/100/1000 Base-T, High-speed USB 3.0
Functions	Print, Copy, Scan
Media Sizes Supported	A4, A5, A6, B5
Printer Type	Laser
Copy Speed	Up to 25 ppm
Mobile Printing	Apple AirPrint, Google Cloud Print, Xerox Print Service Plug-in for Android
