Xerox VersaLink B7025 Service Manual

April 2017
2-66
Xerox® VersaLink® B7025/B7030/B7035 Multifunction Printer
012-211A, 012-221, 012-223
Launch Issue
Status Indicator RAPs
YN
Secure the connections.
Check for an open or short circuit between P/J8711 and P/J8736. The wiring is good.
YN
Repair the open or short circuit.
Enter dC330 code 012-060. Measure the voltage between the finisher PWB P/J8711 pin
1 (+) and ground (-).
The voltage changes.
YN
Check the +24VDC circuit. Refer to the Wiring Diagrams. If the fault persists, install
a new finisher PWB, PL 12.14 Item 1.
Enter dC330 code 012-061. Measure the voltage between the finisher PWB P/J8711 pin
2 (+) and ground (-).
The voltage changes.
YN
Check the +24VDC circuit. Refer to the Wiring Diagrams. If the fault persists, install
a new finisher PWB, PL 12.14 Item 1.
Check the wires and connectors for an intermittent open and short circuit. If the fault per-
sists, install a new stacker motor, PL 12.20 Item 9.
Check the wires and connectors for an intermittent open or short circuit. If the fault persists,
install a new finisher PWB, PL 12.14 Item 1.
012-221, 012-223 Front Tamper Home Sensor Fail Entry
RAP
012-221 The front tamper home sensor failed to actuate within the specified time.
012-223 The front tamper home sensor failed to deactuate within the specified time.
Procedure
Go to the relevant procedure:
• Integrated office finisher installed, 012-221A, 012-223A Front Tamper Home Sensor Fail.
RAP
• Office finisher LX installed, 012-221B, 012-223B Front Tamper Home Sensor Fail RAP.
B
